Specifications
1.Wide applicability2.Anti-dust
3.Protect materials from harm
4.Avoid the materials jam
5.Detection function
Features
Wide applicability
Used for tablets (including abnormal tablets), capsules, gels (including abnormal gels, transparent gels and opaque gels) pills and most solid granules.
Anti-dust
Using our own original high anti-dust sensor technology, the machine works accurately with good stability in heavy dust conditions.
Protect materials from harm
Feeding evenly with quiver, special patent filling part, no breakage of the material.
Avoid the materials jam
Hopper mouth of the special structure, to prevent the materials jam, small mouth bottle can quickly bottling.(Optional)
Detection function
No bottle will not count and fill. Automatically remove bottles of filling abnormalities and a certain size broken tablets. Self-diagnose errors and stop working to make alarm at errors.
Technical Parameters
Applicable for |
00-5 capsules, soft gels, 5.5-12 normal tablets, special shape tablets, coating tablets,3-12 pills |
Capacity |
10~30 BPM |
Working range |
2-9999tablets capsules pills (adjustable) |
Air supply |
0.6 Mpa |
Power supply and consumption |
220V/50HZ 0.6kw |
Size |
320*1260*760mm(estimate) |
N.W. |
120kgs(estimate) |
Remarks |
1. Capacity is subject to the type and size of the bottle and tablet, as well as the quantity filled per bottle; 2. BPM Bottles per minute |
Configuration
Name |
Producer |
Motor |
JSCC International Group |
Photoelectric sensors |
microchip chip and Taiwan electronic elements |
Counting photoelectric sensor system |
Optical components is from Taiwan ,and the microchip chip is from U.S., then developed and produced by our company. |
Pneumatic components |
Air Tac |
Leakage protection |
Schneider |
Switch |
Schneider |
Control Panel |
Using the microchip chip is from U.S , developed and produced by our company. |
Interface |
HITECH(Beijer Electronics Co., Ltd.),Color touch screen |
