Specifications
bucket elevator1. 201,304 stainless steel, carbon steel
2. suitable for regular objects
3. easy to operat
Hot Z type pellet bucket elevator
Bucket elevator is used for grain materials, such as coffe beans, crispy rice, jelly,candy, pistachios, apple slices, dumplings, glutinousrice balls, chocolate, pet food, puffed food, hardware items, medicines and so on.
It mainly applies to vertically hoist granule of food, grain,feed, plastics and chemical sectors.
Working principle:
The material from the hopper bailed on, Veda storage in with ascent to the top or chain conveyor
belt, bypassing the crown chakra downward flip, dou type after the material hoist forward into accepting slot.
It raises the material to a certain height and then parallelly delivery them to the specified location.
Features:
1.The Z type conveyor made of stainless steel,which is safety and health.
2.It has strong structure and less energy consumption.
3. Easy to operate and maintain
Introduction:
1.Materials may upward transportation, and downward transport.
2.Elevator hopper is risen by the chain, vertically elevating bulk materials and
small particles.
3.It has circuit control and switch that realize stopping and feeding
automatically.
4.The machine has the advantages of big hoist capacity and height.
5.The hopper is designed widely to make the materials pass smoothly.
6.The Z type conveyor adopts to vertical transmission which reduces the covered
area, increase work space, and improve the transportation efficiency.
7.The Z-Hoist has good quality and low maintenance.
Technical parameters
| Model | Power | Capacity | bucket size | Weight | Height | Packaging dimensions |
| LYTSZ | 0.75-1.5KW | 3-10m³/H | 1.8L | 550KG | 3940mm | 2050*1350*980mm |
