Specifications
air flow drying machine1)high mechanization
2)good drying uniformity
3)easy to operate and maintain
Hot high efficiency industrial rotary drum air flow drying machine
Air flow drying machine can be named chicken manure dryer, cow dung, horse manure dryer, pig manure dryers, duck manure dryers, goose dung dryer, etc.
Organic manure dryer products fine grain can be used as culture medium, After drying the product can be used as a medium, planting mushroom Agaricus bisporus, also can be sold as breeding turtles, fish, snails, chickens, ducks and feed.
Working principle:
The wet materials after dehydration get into the dryer, copy board for turning in the drum are uniformly distributed, the material in the dryer is evenly dispersed and heat the air full contact, to speed up the drying heat transfer, mass transfer.
In the process of drying, the material in the copy board and hot temperament with slope under the action of the dryer, to another star discharging valve discharge finished.
Introduction and Features:
1.The equipment is mainly composed of heat source, feeding machine, feeder, rotary drum,
material feeder, crusher, induced draft fan, unloader and power distribution cabinet
2.the machine has the high mechanization degree, larger production capacity, can work
continuously.
3. simple structure, good material through the barrel resistance smooth operation, easy to operate.
4. Less failure, low maintenance cost, low power consumption.
5. The scope of application is wide, the uniformity of product drying is good.
6. During drying it can also achieve the purpose of sterilization and deodorization
7. Safe storage moisture of organic fertilizer drying machine can be as high as 70%-80% content of
manure a direct drying to 13%
8. the whole process is accomplished in a closed system ,thus reducing environmental pollution
during drying.
Technical parameters:
| Model | Diameter(mm) | Length(m) | Slope(°) | Speed(r/min) | Capacity(t/h) | Power(kw) |
| LYTYH1.2*6 | 1200 | 6000 | 3 | 5 | 0.5-1 | 5.5 |
| LYTYH1.4*7 | 1400 | 7000 | 3 | 5 | 2-3 | 7.5 |
| LYTYH1.6*8 | 1600 | 8000 | 3 | 5 | 3-5 | 11 |
| LYTYH1.8*9 | 1800 | 9000 | 3 | 4 | 4-5 | 15 |
| LYTYH2.0*10 | 2000 | 10000 | 3 | 4 | 6-8 | 18.5 |
