SIFHEALTH-6.2 Portable Ultrasound Scanner, Probe Type, Ultrasound Machine for Vet and Human

Display size

6.5 inch LED display

Display modes

B, B/B, 4B, B+M, M

Image multiplying factor

3.5MHz/R60 convex array probe: ×0.8, ×1.0, ×1.2, × 1.5,×1 .8, ×2.0 (six modes) ×0.8, ×1.0 (display penetration depth);

E-zoom

magnify 2 times of real time image

Dynamic range

0~120dB adjustable

Focus position

dynamic electron focusing

Image processing

8 γ corrections, frame correlation, point correlation, line correlation, digital filtering, digital edge enhancement and pseudo color processing, etc.

Gray scale

256 levels

Frequency conversion

2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0MHz five periods of frequency conversion; frequency range applies 5.5 MHz/6.0 MHz/6.5 MHz/7.0 MHz/7.5MHz can match high frequency probe.

Measuring function

Distance, circumference/area (method of ellipse, method of loci),

volume, heart rate, gestational weeks (BPD, GS, CRL, FL, HL, OFD,

TTD, AC), expected date of confinement and fetus weight, etc.

Annotation function

hospital name, patient’s name, age and gender;

Kinds of body marks (with probe’s position);

Full-screen character annotation;

Real-time clock display;

Puncture guide

3.5MHz convex array probe can display puncture guide line in B mode.

Gain control

8 segments TGC and overall gain can be adjusted respectively

Image polarity

left and right flip, up and down flip.

Capacity cine loop

real time display 256 consecutive images which are memorized successively

Image playback

series playback or check one by one

Permanent storage

128 images

Output interface

USB port
