Agar-agar Dryer
US$ 50,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
chang gan
Model Number:
DWT
Payment & Shipping
Payment Methods:
Port of Shipment:
shang hai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
chang gan
Model Number
DWT
Type
Other, drying machine
After-sales Service Provided
Engineers available to service machinery overseas
onion dryer when operation, air will be entered into the dehydration dryer and heated through heat exchanger. Being adapted scientific and reasonable cycle method, the hot air will pas through raw materials to be dried on the bed and carry out uniform heat exchange. Under the action of cycle fan, the hot air stream inside each unit of the dryer will carry out hot air cycle. Final air with Iow temperature and high damp will be out. The whole drying process with stably and high effect will be finished.
dehydration dryer Technical parameters
| Type | DWT1.6-I (fed table) |
DWT1.6-II (middle table) |
DWT1.6-III (discharge table) |
DWT2-I (fed table) |
DWT2-II (middle table) |
DWT2-III (discharge table) |
| belt width m | 1.6 | 1.6 | 1.6 | 2 | 2 | 2 |
| drying section length m | 10 | 10 | 8 | 10 | 10 | 8 |
| thickness of the material to be covered mm | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 |
| temperature | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 |
| Areae of heat conduction m2 | 525 | 398 | 262.5 | 656 | 497 | 327.5 |
| steam pressureMpa | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 |
| drying time h | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 |
| power kw | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| overall Dim.m | 12×1.81×1.9 | 12×1.81×1.9 | 10×1.81×1.9 | 12×2.4×1.92 | 12×2.4×1.92 | 10×2.4×1.92 |
