XPS HEAT INSULATION FOAM BOARD EXTRUSION LINEXPS foam board, named as polystyrene extrusion plastic board (XPS for short)has a flawless closed-pore alveolate structure. Its density ,water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower than those of other board heat preservasion materials and they have the characteristics of strong intensity , light material, airtight, anticorrosion, aging resistance, low cost, etc. It has been widely used in the fields of heat preservation and heat insulation in the construction industry, frost resistance of the highway, railway, airport, square and household fitment. It is the generally acknowledged and the best heat preservation material in the market at present.
Main Technical parameters
Model |
Unit |
SMXPS-135/150 |
|
Extruder |
135/36 |
150/34 |
|
Heating power |
KW |
50 |
52 |
Driving motor power |
KW |
75 |
75 |
Thickness of board |
mm |
20,25,30,40,50,60,75,100 |
|
Width of board |
mm |
600,900,1200 |
|
Length of board |
mm |
1200,1250,2450,2500 |
|
Edge of board |
SS flat head (SL lap joint, RC rain groove) |
||
Output |
kg/h |
280-320 |
|
Installed capacity |
KW |
300 |
|
Dimensions(L×W×H) |
mm |
35000×10000×4000 |
|
Total weight |
T |
28 |
|
Application of The Produce
- For heat preservation of steel structure workshop, iron sheet house and colored ripple title;
- For making up the heat insulation board in the refrige ration storehouse for cold preservation and waterproofing;
- For laying the bedding under the road bed of the highway for buffering and controlling the frost heating of the ground;
- For waterproofing and heat preservation of residential building, office building, the factory wall and roof;
- For laying the bedding under the floor for the functions of heat insulation, dampproof and soundproof;
- For heat insulation and heat preservation of the ventilation pipeline of central air conditioner.
