Home > Manufacturing & Processing Machinery > Plastic Machinery > Foam Machinery > PSZ-1520 Automatic EPS Foam Box Machine With Best Price

PSZ-1520 Automatic EPS Foam Box Machine With Best Price

Name: PSZ-1520 Automatic EPS Foam Box Machine With Best Price
Brand: TONGYI
SKU: 137239349
Availability: InStock

PSZ-1520 Automatic EPS Foam Box Machine With Best Price thumbnail-1

PSZ-1520 Automatic EPS Foam Box Machine With Best Price photo-1

US$ 1 - 33,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Product Type:

Other, Foam Box

Place of Origin:

Shandong, China

Contact Supplier Request Quote Chat Now

Longkou Tongyi Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Product Type Other, Foam Box

Place of Origin Shandong, China

Brand Name TONGYI

Model Number PSZ-1520

Voltage 380v

Power(W) 9.5kw

Dimension(L*W*H) 5000x2100x3100

Weight 4800kg

Certification CE

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

EPS Foam Box Machine
1.PLC & touch screen
2.full automatic
3.used for fish box and fruit box machine
4.CE approved

PSZ-1220 Automatic EPS Foam Box Machine with Best Price

EPS foam forming machine mainly includes two parts:

EPS pre-expander:it is used in first foam for polystyrene material which has deat with the foaming agent (just is pre-foam)
EPS foam forming machine:it is used to make eps foam boxes and packaging materials.
A. EPS pre-expander

1. This machine adopts PLC programmable controller and touching screen to carry out automatic production from feeding, temperature control, ration, pressurizing and feeding.
1. Top-grade sealing foaming with constant pressure, high thermal efficiency, save 50% steam or above than continuous foaming machine
2. Adopt high-precision imported pneumatic control valve so that temperature can be controlled at ±1%, EPS grains are at same level with low water content.
3. Correct feeding method can assure even density

B. EPS foam forming machine

1.It adopts Japan Mitsubishi Corporation PLC, imported touch screen, full English display, graphical interfaces intelligent control, achieve man-machine conversation.

2. It can carry out full automatic, semi-automatic, middle startup and manual operation.

3. Taiwan AIRTCA hydraulic system is stable run, low noise, high clamping force.

4. Vacuum system accelerates product shaping speed, shorts the cooling time, reduce product water content.

5. Optimized design is clear and easy with high intensity and high performance-price rate.

6. This machine can carry out heating, cooling, feeding and ingot stripping process to adapt tp different EPS products.

7. Perfect malfunction checkout system and motor protecting system which guarantees safe running of equipment.

Item	Unit	PSZ-900	PSZ-1220	PSZ-1420	PSZ-1520	PSZ-1620	PSZ-1720	PSZ-1820	PSZ-2000
Dimension of stangard matrix	mm	900*800	1200*1100	1400*1300	1500*1400	1600*1500	1700*1600	1800*1700	2000*1900
Dimension of finished product	mm	750650350	1050850350	12201100350	13201200350	14201300350	16101400350	16101400350	18501650350
Max matrix opening	mm	1200	1200	1400	1400	1400	1400	1400	1400
Mini matrix opening	mm	150	150	200	200	200	200	200	200
Steam pressure	mpa	0.5-0.7	0.5-0.7	0.5-0.7	0.5-0.7	0.5-0.7	0.5-0.7	0.5-0.7	0.5-0.7
Cooling water pressure	mpa	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.5-0.6	0.3-0.6	0.3-0.6
Air Pressure	mpa	≥0.5	≥0.5	≥0.5	≥0.5	≥0.5	≥0.5	≥0.5	≥0.5
Fluid drive pressure	kw	3.6	5.5	5.5	5.5	5.5	5.5	5.5	7.5
Power of vacuum pump	kw	4	4	4	4	5.5	5.5	5.5	5.5
Inspiratory capacity of vacuum pump	M³/h	165	165	165	165	230	230	230	230
