2014 Poultry Farm Disinfection Sprayer for Truck SFXD-CLTD
Parameter:
Spraying distance |
3m (adjustable) |
|
||
Particle size |
30-150 μm |
|
||
Solution Proportion |
0.4%-4% |
|
||
Spraying time |
1-100min (adjustable) |
|
||
Spraying volume (per set) |
4.8L/min |
|
||
Parameter under 4bar water pressure (per nozzle) |
|
|||
Air pressure (bar) |
Flow rate (l/h) |
Air delivery (l/min) |
||
4.6 |
59 |
106 |
||
5.3 |
40 |
132 |
||
5.6 |
32 |
145 |
||
6.0 |
26 |
158 |
||
6.3 |
20 |
172 |
||
6.7 |
15.9 |
185 |
||
7.0 |
12.7 |
198 |
||
Warranty
Parts |
Warranty |
Exception |
Spraying system |
36 months |
From the date of receiving the shipment in the destination port, any quality failures, we will offer free remote technical advice& support and also new parts if necessary with the copy of original Commercial Invoice. But below conditions is not included in this warranty clause: 1. Blocking and/or damages caused due to spraying strong corrosive solutions; 2. Damages caused due to structure and/or parts change without authorization; 3. Damages caused due to operating and/or maintenance not according to the operation manual; 4. Lost and/or damages caused due to man-made reasons or overload use; 5. Force majeure: earthquake, flood, fire and other disasters can not be foreseen. |
Control System |
12 months |
|
Water Filter |
3 months |
|
Sensor |
3 months |
|
Pump |
3 months |
|
Solution Mixer |
3 months |
|
Solenoid valve |
12 months |
|
Air compressor |
Not included |
|
Accessories |
Not included |
