Auto Pallet Drum&Tote Filler JP-1000T
*Product Application:
Applications include free flowing to viscous products, including chunky products. Fill volumes from 200
to 2 ton at high flow rates with accuracies up to ±0.2% dependent upon drum size and type of product.
*Technical Specification:
1). Product : Free flow to high viscosity
2). Capacity : 50-60 drums/Hr dependent upon drum size and type of product;
3). Container Volume: 200Ltr drum/1ton IBC
4). Voltage supply :380V,3P,50Hz(Upon request)
5). Filling accuracy : Class X (0.5) (0.2%);
6). Filling mode : Above or under liquid level with fast&dribble fill
*Type of Build:
1) Stainless Steel or Zinc Painted Finish
2) In effect, performs Debunging, Filling, Bunging, Clinching, Stenciling, Palletizing in a small area with as little as one operator
*Filling System includes:
1). No spilling of the product onto clean drums and roller conveyor with hood cover under the nozzle.
2). Manual/Net/Gross Filling. Auto two stages fast fill&dribble fill;
3). Quick-release, fast inter-changeable lance for easy and fast maintenance; SS316 straight pipe;
4). Top/Low Fill, auto lowering of lance assembly together with the hood cover and retract to its original up position;
5). Heavy duty weighting platform mounted single load cell, overload protected;
6). Drums are fed to filler on a pallet of 4 (2x2) infeed conveyor - are either powered or gravity.
7). spring assists to close filling nozzle in the even of power failure;
8). Safety Interlock for nozzle fully close before lance can withdraw from drum;
*Control system includes:
1). Siemens PLC with touch screen panel
2). Mettler Toledo loal cell and displayer
3). Manual/Net/Gross Filling. Auto two stages fast/dribble fill
*Optional Item
1). PLC to DCS synchronization and simulation;
2). Available to suit Hazardous Environments with Ex-proof system;
3). Nozzle diving system.
Call/email now for a quick response to your application questions.
