12 core fiber cable JET for telecomunication

Name: 12 core fiber cable JET for telecomunication
Brand: NECERO
Price: USD $0.2 - 0.7 / Meter

FOB Price

USD $0.2 - $0.7 / Meter

1000 Meters(Min.Order)

Supply Ability 8000 Kilometer / Kilometers per Month
Port Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	NECERO	Model Number:	JET
Type:	Cat 7

Product Description

12 core fiber cable JET for telecomunication

Description

Aerial optical fiber cable,unitube structure optical fiber cable, outdoor fiber optic cable

JET Outdoor Aerial Optical Fiber Cable with Maximum Fiber Number of 24 Cores
Strength Member: two Steel wire
Fiber: can choose SM 9/125 or MM: 62.5/125 ,50/125, OM1,OM2,OM3,OM4

Characteristics

Low dispersion and attenuation

Good mechanical and temperature perfermance
High strength loose tube that is hydrolysis resistance
Special tube filling compound ensure a critical protection of fiber
With small cable diameter, light cable weight
Crush resistance and flexibility
The following measures are taken to ensure the cable watertight:

* Loose tube filling compound

* 100% cable core filling

Optical Characteristics

		G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20°C)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelength λcc		≤1260nm	≤1480nm

Technical Parameters

Cable Type	Fiber Count	Cable Diameter mm	Cable Weight kg/km	Tensile Strengt Long/Short Term N	Crush Resistance Long/Short Term N/100mm	Bending Radius Static /Dynamic mm
JET 2~12	2~12	4.2±0.3	12	60/150	300/1000	10D/20D
JET 14~24	14~24	4.6±0.3	15	60/150	300/1000	10D/20D
JET 26~36	26~36	5.1±0.3	18	60/150	300/1000	10D/20D
JET 38~48	38~48	5.6±0.3	22	60/150	300/1000	10D/20D

Successful Project

Based on the good quality product ,strong technical support and and well train sale team,Necero has many successful project case in home and aboard.

1.Daya Bay Nuclear Power Station 2.Shanghai Subway
3.Shenzhen TV Center 4. Fo-Kai Highway
Kaohsiung police station in Taiwan 5.Frankfurt Airport
Hongkong Disneyland Hotel 6. St. Anthony's School in Singapore

Factory Overview

Exhibition Show

Our Clients

cable jet

why choose Necero?

>>Wide range and every level Price Products for Options.

>> Strong Strength—One of the best and largest fiber optic cable manufacturer in southern China.

>>Professional R&D Department, we own 20 patents,OEM and ODM Service is available.

>>Advanced equipment and strict test.

>>Flexible order processing to ensure a fast delivery time.

>>Knowledgeable and Patient Sales.

>>Over 12 Hours Online Consulant on working days,any enquiry will be replied in 24 hours.

>>We never Sell or Share Your information.
