Description
02~12 fiber, Φ900μm Tight buffer fiber, Aramid yarn, LSZH Jacket.
Standards
·Comply with Standard YD/T 1258.4-2005, ICEA-596, GR-409, IEC794, etc; and meet the requirements of UL approval for OFNR.
Characteristics
1.good uniformity of the outer diameter of tight buffer fiber and excellent strippability
2.good performance of flame-retardant
3.low-induced attenuation within the operating temperature range
4.Excellent geometrical dimension of the fiber
Cable Code
MPC-02 |
MPC-04 |
MPC-06 |
MPC-08 |
MPC-10 |
MPC-12 |
|
Cable Diameter (mm) |
4.1±0.25 |
4.8±0.25 |
5.1±0.25 |
5.6±0.25 |
5.8±0.25 |
6.2±0.25 |
Cable Weight (kg/km) |
11.0 |
18.4 |
22 |
24 |
27 |
31 |
TBF Diameter |
900±50μm |
|||||
Mechanical Characteristics
|
Environmental Characteristics
Transport Temperature |
-20°C~+60°C |
Storage Temperature |
-20°C~+60°C |
Installation Temperature |
-5°C~+50°C |
Operating Temperature |
-20°C~+60°C |
