Specifications
2 core indoor optic fiber cableexcellent strip kevlar strength cable
excellent geometrical optic cable
ISO9001:2000 TLC
Our customers
Description
DIC2F ,2 fiber, Figure 8 structure,Φ900μm orΦ600μm Tight buffer fiber, Aramid yarn, PVC Jacked
Characteristics
1.Good uniformity of the outer diameter of tight buffer fiber and excellent strippability
2.good performance fo flame-retardant
3.Excellent geometrical dimension of the fiber
4.Low induced attenuation within the operating temperature range
Cable code
|
ZCC-III |
ZCC-II |
ZCC-I |
Cable Diameter(mm) |
(6.0±0.4)×(2.8±0.2) |
(4.2±0.4) ×(2.0±0.2) |
(3.4±0.4) ×(1.6±0.2) |
Cable Weight(kg/km) |
15.6 |
10.5 |
7.3 |
TBF diameter |
900±50μm |
900±50μm |
600±50μm |
Mechanical Characteristics
Tensile Strength |
Long term |
100N |
|
Short term |
200N |
||
Crush Resistance |
Long term |
200N/100mm 100N/100mm |
|
Short term |
1000N/100mm 500N/100mm |
||
Bending Radius |
Dynamic |
20*H (Cable Axis) |
|
Static |
10*H (Cable Axis) |
||
Optical Characteristics
|
|
50/125μm |
62.5/125μm |
G652 |
G655 |
Attenuation(+20°C) |
@850nm |
≤3.5dB/km |
≤3.5dB/km |
|
|
@1300nm |
≤1.5 dB/km |
≤1.5 dB/km |
|
|
|
@1310nm |
|
|
≤0.45Db/km |
≤0.50Db/km |
|
@1550nm |
|
|
≤0.30Db/km |
≤0.50Db/km |
|
Bandwidth(ClassA) |
@850nm |
≥500Mhz·km |
≥200Mhz·km |
|
|
@1300nm |
≥1000Mhz·km |
≥600Mhz·km |
|
|
|
Numerical Aperture |
0.200±0.015NA |
0.275±0.015NA |
|
|
|
Cable Cut-off Wavelength λcc |
|
|
≤1260nm |
≤1480nm |
|
|
Attenuation at temperature cycling α(-20°C~+85°C)
|
@1300nm |
≤0.25dB/km |
≤0.25dB/km |
|
|
@1550nm |
|
|
≤0.10dB/km |
≤0.10dB/km |
|
Environmental Characteristics
Transport Temperature |
-20°C~+60°C |
Storage Temperature |
-20°C~+60°C |
Installation Temperature |
-5°C~+50°C |
Operation Temperature |
-20°C~+60°C |
OEM/ODM SERVICES ARE PROVIDED
We can produce the cable on your need
Don't hesitate to contact me if you have any questions about the products
