FTTH indoor cable with 1 core G657A1 FRP
Product Description
FTTH The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two sides. Then the cable is completed with a black or color LSZH sheath.
Cable Structure:
Application:
- Adopted to indoor distribution.
- Suitable for aerial duct
- Long distance and local area network communication.
Characteristics:
· Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
transmission property;
· Two parallel FRP strength members ensure good performance of crush resistance to protect the
fiber;
· Simple structure, light weight and high practicability;
· Novel flute design, easily strip and splice, simplify the installation and maintenance;
· Low smoke, zero halogen and flame retardant sheath.
Method of installation:
Other methods of installation are also available.
| Fiber Count |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100mm |
Bending Radius Static /Dynamic mm |
| 1 | (2.0±0.2)×(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
| 2 | (2.0±0.2)×(3.4±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
| 3 | (2.0±0.2)×(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
| 4 | (2.0±0.2)×(4.0±0.2) | 10 | 30/60 | 300/1000 | 15/30 |
Packaging & Shipping
Company Information
FAQ
How will you control the quality of the fiber optic cable?
We will check each details of the cable.
Sheath: material, color, thickness, printing, feeling.
Cable structure: as per the spec of the cable.
OTDR report for each fiber in the cable.
How will you protect the fiber when packing?
We will use the exporting wodden reel outside.
With EPE foam inside to protect the fiber, and make sure the reel is user-friendly,
easy to load and install.
How will the goods be shipped?
By sea if the goods is not in urgent need.
By air if the goods is needed urgently.
We have best choices of forwarder for both sea and air.
