FTTH Indoor Cable 8cores
| Packaging Details: | wooden drums or as your request |
|---|---|
| Delivery Detail: | within 15 days |
Description,
There are high quality 250μm fibers are placed in a loose tube made of a high modulus plastic which is filled with a water resistant filling compound.Two Parallel steel wires are placed at the two sides of the steel tape.The cable is completed with a polyethylene(PE) sheath.
Characteristics
1.Small diameter,light weight and friendly installation
2.High strength loose tube that is hydrolysis resistant
3.Special tube filling compound ensure a critical protection of fiber
4.Two parallel steel wires ensure tensile strength
5.long delivery length
6.Crush resistance and flexibility
Pictures
Optical Characteristics
|
G.652 |
G.655 |
50/125μm |
62.5/125μm |
|
|
Attenuation (+20°C) |
@850nm |
|
|
≤3.5dB/km |
≤3.5dB/km |
@1300nm |
|
|
≤1.5dB/km |
≤1.5dB/km |
|
@1310nm |
≤0.45dB/km |
≤0.5dB/km |
|
|
|
@1550nm |
≤0.30dB/km |
≤0.5dB/km |
|
|
|
|
Bandwidth (Class A) |
@850nm |
|
|
≥500MHz.km |
≥200MHz.km |
@1300nm |
|
|
≥1000MHz.km |
≥600MHz.km |
|
Numerical Aperture |
|
|
0.200±0.015NA |
0.275±0.015NA |
|
Cable Cut-off Wavelength λcc |
≤1260nm |
≤1480nm |
|
|
|
Technical Parameters
Cable Type |
Fiber count |
Cable Diameter MM |
Cable weight kg/km |
Tensile strength Long/short Term N |
Crush Resistance Long/short Term N/100mm |
Bending Radius Static/dynamic MM |
GYXTPY |
1-2 |
5.6 |
34 |
500 |
500 |
10D/20D |
GYXTPY |
3-6 |
6.0 |
38 |
500 |
500 |
10D/20D |
GYXTPY |
7-12 |
6.5 |
43 |
500 |
500 |
10D/20D |
Fiber Count |
Cable Diameter mm |
Cable Weight Kg/km |
Tensile Stregth Long/Short Term N/100mm |
Crush Resistance Long/Short Term N/100mm |
Bending Radius Static/Dynamic mm |
1 |
(2.0±0.2)*(5.0±0.2) |
20 |
60/120 |
300/1000 |
15/30 |
2 |
(2.0±0.2)*(5.0±0.2) |
20 |
60/120 |
300/1000 |
15/30 |
1 |
(2.0±0.2)*(5.6±0.2) |
21 |
60/120 |
300/1000 |
15/30 |
4 |
(2.0±0.2)*(5.6±0.2) |
21 |
60/120 |
300/1000 |
15/30 |
