Semi Automatic Bottle Blowing Machine to Make Pet Bottles

Semi Automatic Bottle Blowing Machine to Make Pet Bottles thumbnail-1
Semi Automatic Bottle Blowing Machine to Make Pet Bottles photo-1
US$ 3,050 - 3,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Bottle
Plastic Processed:
PET
Contact Supplier Request Quote Chat Now
Taizhou City Huangyan Yuanda Machinery Manufacture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Bottle
Plastic Processed PET
Blow Moulding Type Stretch Blow Moulding
Automatic No
Place of Origin Zhejiang, China
Brand Name yuqi
Voltage 380V, 60Hz/ 3PH or special
Power(W) 3-10KW
Dimension(L*W*H) 145*60*170cm
Weight 1100kg
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas
bottles

 semi automatic bottle blowing machine to make pet bottles

SEMI-AUTOMATIC  PET BOTTLE BLOWING MACHINE



General Information

YD-1500
One Blower & One Heater

YD-1500
Two Blower & One Heater

  Clamping Force

10T

  Clamping Stoke

160mm

  Max.Stretching Stroke

360mm

  Number of Cavities

1 Cavity

2 Cavity 2Pcs

  Theoretical Output

0.1-1.5L:600-800 BPH

0.1-1.5L:1000-1600 BPH

  Max.Mould Thickness

220mm

  Mould plate size

470x350mm

  Voltage Standard

380v/3PH/50Hz or special order

  Total Power(Full Loaded)

3-10KW

5-15KW

  Min air compressor

1.0m3/min 3.0Mpa

1.2m3/min 3.0Mpa

Net dimension & Weight(LxWxH)

  Blow Molding Machine

145x60x170cm

145x60x170cm 2Pcs

  Pre-heater

180x70x140cm

  Net Weight

1.1T

1.6T

Container

  Container Volume

1.5L

  Neck Diameter Range

8-60mm

  Container Diameter

115mm

  Container Height

360mm















Features:







- Produce bottle from 0.1L to 1.5L (2cavity), 3L (1cavity)







- Output capacity up to 1000bph for 0.5L with 2cavity bottle blow mold







- Advanced PLC control system with a use-friendly panel and time control precision of PLC up to 0.01second







- Equipped with special designed air storage unit







- Adopt to far infrared preform heater, average and enough heating







- Heating lamps are adjustable in directions to suit various preforms







- Independent temperature control for different heating lamp to get ideal preform heating results
