Home > Products > Belt filter press > Rubber hydraulic press with good price
Rubber hydraulic press with good price
- 10 Set / Sets per Month
- shanghai
You May Like
Product Details
Place of Origin | Jiangsu, China | Brand Name | BOEEP | |
Model Number | ZDY1.5 |
Product Description
Rubber hydraulic press with good price
Specifications:
1.automatic filter cloth washing
2.long life belt cloth
3.save energy
4.High capacity
Product Features :
1. Material of the main structure : SUS304/316
2. Belt : Has a long service life
3. Low power consumption, slow-speed of revolution and low noise,
4. Adjustment of belt: Pneumatic regulated, ensures the stability of the machine
5. Multi-point safety detection and emergency stop device:improve the operation.
6. The design of the system is obviously humanized and provides convenience in operation and maintenance.
Product Application:
1. Sludge dewatering of industry waste water
2. Separation of liquid and solid in food, chemical and mining industries
3. Sludge dewatering in butching and animal husbandry
Product Data:
ZDY1.0 | ZDY1.5 | ZDY2.0 | Note | ||
Belt width(mm) | 1000 | 1500 | 2000 |
| |
Treatment capacity Inlet sludge concentration (SS1-5%) | 6.5~10.5 | 12~20.5 | 18~30 | Depending on the types of sludge | |
D.S Dried sludge(kgds/h) | 98~158 | 180~308 | 240~450 | Depending on the types of sludge | |
Moisture content of the filter cake(%) | 75~85 | 75~85 | 75~85 | Depending on the types of sludge | |
Service power(kw) | The motor for driving belt(frequency control) | 0.37 | 0.75 | 0.75 |
|
The motor for mixing | 0.37 | 0.55 | 0.75 |
| |
The motor for drum thickener | 0.37 | 0.55 | 0.55 |
| |
RC Collecting Tray for Filtrate | With | With | Without |
| |
Reference appearance size(mm) | L | 2600 | 3300 | 3450 | Before ordering, please ask for the actual installation size drawing |
W | 1550 | 2150 | 2900 | ||
H | 2540 | 2550 | 3100 | ||
Base dimension L1 x W1(mm) | 2100 x1330 | 2450 x1860 | 2715 x2420 |
| |
Reference weight (kg) | 1210 | 2200 | 2850 |
|
Product Details:
BOEEP belt filter Press, which is a latest advancedsludge dewatering technique. It’s characterized by small footprint and wide applications. It can be used for different sludgein varieties of industries includingpetrochemical processing, light industry,electroplating, printing & dyeing, food & beverage, chemical fiber, paper-making, proteins,livestock, pharmacy and leather etc.
The concentration belt sludge filter Press is slightly influenced by the load fluctuation of sludge and the water content’s rate of sludge cakes is low. The machine is easy for worker’s operation and management.
ZDY-TypeDrum enrichment belt filter press dewatering machine: mainly used to treat sludge which is ready to be concentrated through rotating and concentrating(e.g. residual sludge in Method A/O). This equipment has double functions of sludge concentrating and dewatering,and its treating capacity increase more than that of old press filter.
Treatment Flowchart :
Project Site:
About us:
Company Introduction
Jiangsu BOE Environmental Protection Technology Co., Ltd. (BOEEP), lying in the traditional Chinese famous city—Yangzhou, is a professional environmental protection equipment manufacturer and engineering service enterprise.
BOEEP started to set foot in the environmental protection industry from 1988 and is mainly engaged in research on biological wastewater treatment technology and industrialization application, research and development, manufacture and sales of competitive products and technology service, general contracting of environmental protection engineering including design, installation and commissioning, and etc.
Total 6 series and over 50 kinds of environmental protection equipment developed and manufactured by BOEEP cover sludge dewatering equipment, mechanical bar screens, dissolved air flotation equipment, sludge scrape and suck equipment, dosing and mixing equipment, and conveying and pressing equipment.
As a famous leading technology environmental protection equipment manufacturer and engineering service enterprise, BOEEP is committed to create value for employees, customers, suppliers, company, shareholders, and society, realize the sustainable development.
If you are interested in our product, contact me!
We will do our best to be of service for you !
Contact Us
- Jiangsu BOE Environmental Protection Technology Co., Ltd.
- Contact nameMandy Zhou Chat Now
- Phone0086-0514-87848766
- AddressNo.88, Zhaozhuang Road, Yangmiao, Hanjiang, Yangzhou, Jiangsu
