API 5L Grade X60 PSL2 Longitudinal Welded Steel Pipe

US$ 500 - 850 MOQ: 5 Metric Tons

Key Specifications

Standard:

Grade:

Thickness:

4.5, 16

Cangzhou Shenzhou Steel Pipe Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin

Delivery Detail:

Delivery time depends on order quantity.

Thickness 4.5, 16

Section Shape Round

Outer Diameter 219 - 610 mm

Place of Origin Hebei, China

Secondary Or Not Non-secondary

Application Oil Pipe

Technique SAW

Certification API

Surface Treatment Other, epoxy,3PE,galvanized or according to your requirement

Alloy Or Not Non-alloy

Specifications

OD:219-610mm,4.5-16mm
Standard:ASTM/DIN/ASME/API
Material:A106,A53,X42-X70,Q195,Q235
API,ISO certificate
SGS Inspection

Carbon Steel welded Pipe
Standard	ANSI,ASTM ,API.DIN,GB.JIS
Material	A106 Gr A,B,A53 Gr B,ASTM A179,A106GrB,ASTM A53GrB,St42,St45,A179,A135,A315B,A214C A333 Gr 6,A335 P11,A335 P22,TP304,TP321,TP316,TP304L,TP316L,A335 P5,ST37,ST35.8,ST52,1.0309,
OD	219-610mm
WT	SCH5,SCH10,SCH20,SCH40,SCH60,SCH80,SCH100,SCH120,SCH160,XXS
Usage	Structure Use,water transport,Building,Machinery,Traffic,Aviation,Oil development ect.
OD Tollerance	D<50mm,+-0.5mm ,D>50MM,+-1%
WT Tollerance	WT +-12.5%
Chemical	C:0.17-0.24%,Si:0.17-0.37%,MN:0.35-0.65%,P:<0.035%,S:<0.035%,Cu:<0.25%,Ni<0.25%,Cr:<0.25%
Tensile strength	390MPA
Yield Point	WT<16MM 245MPA,WT 16-30MM 235MPA
Elong-Ation	20
other test	HY,ET according to request
Length	2-12m Random,5.8M FIXED,6M FIXED,9M FIXED
Suface	Black paint as rusty protect
Ends	2"below plain ends,2" above beveled ends
Methord	140mm below cold drawn,140mm above hot rolled,273mm above hot expand
Packing	6 steel strip,bundles,Caps , plastic wrap,loading belt
