Support for external stereo audio signal transmission VGA transmitter
Descpription
The PW-DT206F VGA Extender could transmission high-definition video long distance through a single fiber cable , external independent audio and other function, can adapt to a variety of complex applications. The device has a superior image processing and transmission capacity, so that the signal transmission more smooth and stable, it is a good solution with a reliable, high-performance, efficient VGA, signals to extend the way.
Features
- Transmit VGA video and audio over long distances through the Fiber, up to 20KM ;
- The highest resolution HD video signals up to1080P @ 60Hz;
- Compliance with VGA standard protocol;
- Support for external stereo audio signal transmission;
- It can automatically identify and configure a variety of display modes;
- Built-in automatic equalization system, the picture is smooth, clear and stable;
- Built-in ESD Protection Circuit, comprehensive protection system security;
- Easy to install, plug and play, no need to set;
Parameter |
Description |
|
Video |
Signal Type |
VGA |
BW |
380MHz |
|
Resolution |
1024X768 @ 60fps 1280X720@ 60fps 1280X800@ 60fps 1280X1024@ 60fps 1440x900 @ 60fps 1660x1200 @ 60fps 1680x1050 @ 60fps 1920x1080 @ 60fps |
|
Audio |
Port |
3.5mm Stereo Audio Socket |
Type |
Stereo |
|
Fiber Optic |
Cable Type |
Signals Fiber |
Max Transmission Distance |
SC/FC Connector, 20KM |
|
Keyboard And Mouse |
Port |
USB |
Other |
Power |
Adapter:DC 5V/2A |
Power Dissipation |
Max: 4W |
|
Temperature |
Operating:-5℃ ~ +70℃ |
|
Humidity |
Operating:5% ~ 90% |
|
Size |
102*96*25mm |
|
Warranty |
1 Year |
|
Port Name |
Function |
VGA IN/OUT |
VGA signal input/output |
AUDIO IN/OUT |
Stereo audio input/output |
DC/5V |
The power adapter input |
PC IN |
Keyboard and mouse |
Fiber |
FC |
LED indicator |
Description |
LINK |
Connect light |
STA |
Communications equipment indicator light |
PWR |
System power indicator |
- The VGA signal source access VGA Extender transmitter,
- Stereo audio access VGA Extender transmitter,
- The receiving end VGA Extender connected to a display device (such as
- high-definition TV, splicing screen, etc.),
- The VGA extender output audio access receiving end audio equipment,
- Use network cable to connect the sender and receiver of the Ethernet port,
- The sender and the receiving end on the power, when the lights are on, the system running.
Diagram
|
