high speed paper slitting rewinding machine
Negotiable
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- tianjin
You May Like
- Best quality factory price jumbo roll paper machine
- Toilet Paper Cutter/Kitchen Towel Cutting Machine Price with High Performance
- N Fold Hand Paper Towel Dispenser Packaging Machinery Manufacturer
- Automatic paper recycling machine for produce craft paper from www.frdpapermachine.com
- Durable and sturdy spiral paper tube machine
- Durable and sturdy corner protectors
Product Details
Condition: | New | Product Type: | Paper Core Machine | Processing Type: | Paper Slitting and Rewinding Machine |
Place of Origin: | Hebei, China | Brand Name: | unipand | Model Number: | UNI-1600A |
Voltage: | 380V,3phase,4wire | Power(W): | 1.5KW | Dimension(L*W*H): | 2200*2000*1500mm |
Weight: | 1000kg | Certification: | CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
UNI -1600A Slitter1.Jumbo roll width:40-1600mm
2.Jumbo roll unwind max diameter:1500mm
3.Finish roll max diameter:750mm
UNI-1600A Slitter Main Specification and Equipment:
Parameter
jumbo roll width | 40-1600mm | jumbo roll unwind max diameter | 1500mm |
finish roll max diameter | 750mm | slitting speed | 200m/min |
slitting range | 50-700g | involution method | iron tube pressure stalk involution |
quantity of blade | 21set | paper giving way | Jack |
speed adjust | electromagnetic | power supply | 380V,3phase,4wire |
Control System
driving parts | CHNT | signal parts | speed table |
Size (mm)
rewind and unwind(L*W*H) | 2200*2000*1500 | up knife | 105*70 |
down knife | 105*80 | weight | 1000kg |
Driving System
main motor | 1.5KW | moving speed | 1400r/min |
edge-attracting blower | manual | rewind speed gear down | pulley and sprocket |
driving way | chain and belt | bearing | Wanxiang |
tension adjust | manual,gore the spring friction plate |
Contact Us
- Cangzhou Unipand Fluid Machinery & Equipment Co., Ltd.
- Contact nameHurry Liu
- Phone86-0317-5304279
- Addressfuyang sorth road Cangzhou,Hebei
