Specifications
cow milking systemsPipeline milking units
Milk delivery line
Specifications:
This series product can recycle the residual milk which is attached to the main pipeline. Throughly clean the dirt in the main pipeline especially in hot summer, which can reduce bacterial content and fresh the milk .Save water and electricity.To large extent, it reduced the loaded and unloaded trouble of cleaning the inner dirt in main pipeline.This series goes into <The 2009 -2011 Directory of National Support and Dissemination > <The 2010 Directory of National Allowance for Agricultural Machinery Purchase>, and benefits from the National Allowance.This series are mainly for adult cows to milking. Suitable for large and medium-sized farm or milk collection station to provide advanced centralized milking equipment.
Technical parameters: | |||||||
Model |
9JY-1*14 |
9JY-1*16 |
9JY-1*18 |
9JY-2*8 |
9JY-2*12 |
9JY-2*16 |
9JY-2*20 |
Price |
USD 970 / Model |
USD 1050 / Model |
|||||
Working Vacuum |
50Kpa |
50Kpa |
50Kpa |
50Kpa |
50Kpa |
50Kpa |
50Kpa |
Pulsation Ratio |
60/40 |
60/40 |
60/40 |
60/40 |
60/40 |
60/40 |
60/40 |
Frequency |
60 ± 3 RPM |
60 ± 3 RPM |
60 ± 3 RPM |
60 ± 3 RPM |
60 ± 3 RPM |
60 ± 3 RPM |
60 ± 3 RPM |
Vacuum pump power |
5.5 KW |
5.5 KW |
5.5 KW |
5.5 KW |
2*4 KW |
2*4 KW |
2*5.5 KW |
Vacuum pump speed |
2300L/min |
2300L/min |
2300L/min |
2300L/min |
2*1400L/min |
2*1400L/min |
2*2300L/min |
Milk pump speed |
5T/h |
8T/h |
8T/h |
8T/h |
20T/h |
20T/h |
20T/h |
Milk pump power |
1.5KW |
2.2KW |
2.2KW |
2.2KW |
4KW |
4KW |
4KW |
Factory Scene:
Producing Line:
How to Order:
Consult → Place Order (Design Sample) → 30% Full Payment → Processing Planning → Large Production → Quality Control (Test) → 70% Full Payment → Delivery
