Tianjin specialized manufacturer cold rolled steel coils
- 50000 Ton / Tons per Month
- Tianjin
- T/T
Product Details
Standard: | AISI, ASTM, BS, DIN, GB, JIS | Grade: | SPCC-SD,SPCC 01 | Thickness: | 0.14-2mm |
Place of Origin: | Tianjin, China | Brand Name: | brilliant steel | Model Number: | various |
Type: | Steel Coil | Technique: | Cold Rolled | Surface Treatment: | Other, as request |
Application: | Ship Plate | Special Use: | Wear Resistant Steel | Width: | 600-1500,mm |
Length: | in coil |
Product Description
Specifications
1.China manufacturer2.Comepetitive price
3.Best service
4.Fast delivery
1.specification
Grade | Thickness | Width | Length | Remarks |
DC01/SPCC-SD SAE1008 | 0.3-2.5mm | 1000-1500mm | Coil/sheet | Commercial grade |
SPCC-1B/D | 0.12-2.0 | 600-1500 | Coil | Full hard |
SPCC/08AL | 0.12-1.5mm | 600-1000mm | Coil/sheet | Commercial grade |
SPCD/DC03 | 0.4-2.5mm | 1000-1500mm | Coil/sheet | DDS |
SPCE/DC04 | 0.4-2.5mm | 1000-1500mm | Coil/sheet | DDS |
SPCF/DC05 | 0.4-2.5mm | 1000-1500mm | Coil/sheet | EDDS |
Tolerance of thickness:
Thickness, mm | <630 | 630~<1000 | 1000~<1250 | 1250~<1600 | ≥1600 |
<0.25 | ±0.03 | ±0.03 | ±0.03 | - | - |
0.25~<0.40 | ±0.04 | ±0.04 | ±0.04 | - | - |
0.40~<0.60 | ±0.05 | ±0.05 | ±0.05 | ±0.06 | - |
0.60~<0.80 | ±0.06 | ±0.06 | ±0.06 | ±0.06 | ±0.07 |
0.80~<1.00 | ±0.06 | ±0.06 | ±0.07 | ±0.08 | ±0.09 |
1.00~<1.25 | ±0.07 | ±0.07 | ±0.08 | ±0.09 | ±0.11 |
1.25~<1.60 | ±0.08 | ±0.09 | ±0.10 | ±0.11 | ±0.13 |
1.60~<2.00 | ±0.10 | ±0.11 | ±0.12 | ±0.13 | ±0.15 |
2.00~<2.50 | ±0.12 | ±0.13 | ±0.14 | ±0.15 | ±0.17 |
2.50~<3.15 | ±0.14 | ±0.15 | ±0.16 | ±0.17 | ±0.20 |
≥3.15 | ±0.16 | ±0.17 | ±0.19 | ±0.20 | - |
Tolerence of width
width, mm | |
<1250 | ≥1250 |
+3 0 | +4 0 |
Hardness:
HRB | 50 | 65 | 74 | 85 |
Thickness, mm | >2.40 | >1.95 | >1.68 | >1.35 |
2.Chemical composition.
Purpose | Grades | Yield strength/Re/MPa(1) | Tensile strength/ Rm/MPa | Elongation/A80/%(2) | r90 | n90 |
Commercial | DC01 | ≤280 | 270-410 | ≥28 | - | - |
Drawing | DC03 | ≤240 | 270-370 | ≥34 | ≥1.3 | - |
|
Purpose | Grades | Yield strength/Re/MPa(1) | Tensile strength/ Rm/MPa | Elongation/A80/%(2) | 180o Bend test | ||||
h < 0.4 | ≥0.4~<0.65 | ≥0.6~<1.0 | ≥1.0~<1.6 | ≥1.6~<2.0 | b≥20mm | ||||
Commercial | SPCC | - | ≥270 | ≥32 | ≥34 | ≥36 | ≥37 | ≥38 | d=0a |
Deep drawing | SPCD | ≤240 | ≥270 | ≥36 | ≥36 | ≥38 | ≥39 | ≥4O | d=0a |
|
3.Prevention of rust.
4.Product show
5.Container information
6.Other product
7.Contact
