Jelly Fruit Jelly Gelatin Decanter Centrifuge

FOB Price

US$ 15,000 - 68,000 / Unit

1 Unit(Min. Order)

Port Dalian Port or other Chinese port by Selection
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Centrifuge
Product Type	Other, Waste water and other liquid treatment	Place of Origin	Liaoning, China
Brand Name	Fuyi	Model Number	LW
Voltage	380V 50Hz or Customize by order	Power(W)	15Kw to 60Kw
Weight	1200Kg to 15000Kg	Certification	ISO9000:9001
Warranty	24 months	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

Our company Mode LW series decanter centrifuge can apply for various waste water or oil , liquid treatment .

The decanter centrifuge is a horizontal centrifuge with continuous feeding and continuous discharging. The settling speed is determined by particle size, particle shape, difference in density between solids and liquids as well as their viscosity.

All parts coming into contact with the product are made of stainless steel.
3-phase AC motor for controlled torque starting via frequency converter
Approximately 80 to 90 % of the oil is recovered.
Low personnel costs due to continuous and automatic operation.
Highest g-force for higher solids output
Adjustable bowl speed via VFD
Automatic adjustment of differential speed via VFD
Two motor drive
Belts for both primary motor and secondary motor

Model	LW300×1200	LW355×1600	LW400×1800	LW450×1800	LW530×2280
Bowl Diameter mm	300	355	400	450	530
Bowl Length mm	1200	1600	1800	1800	2280
Length to diameter ratio	1:4	1:4.5	1:4.5	1:4	1:4
Speed r/min	4200	3800	3400	3450	2700
Separation Factor	3000G	2868G	2587G	3000G	2150G
Screw differential r/min	5-30stepless adjustable	2-20stepless adjustable	2-25stepless adjustable	2-25Stepless adjustable	3-20Stepless adjustable
Motor kw	Main11,Vice 4	Main 15,Vice 5	Main 22vice7.5	Main 30 Vice 11	Main 45 vice 15
Driving	Dual motor ,frequency	Dual motor ,frequency	Dual motor ,frequency	Dual motor ,frequency	Dual motor ,frequency
Noise db(A)	≤85	≤85	≤85	≤85	≤85
