Specifications
Our company Mode LW series decanter centrifuge can apply for various waste water or oil , liquid treatment .
The decanter centrifuge is a horizontal centrifuge with continuous feeding and continuous discharging. The settling speed is determined by particle size, particle shape, difference in density between solids and liquids as well as their viscosity.
- All parts coming into contact with the product are made of stainless steel.
- 3-phase AC motor for controlled torque starting via frequency converter
- Approximately 80 to 90 % of the oil is recovered.
- Low personnel costs due to continuous and automatic operation.
- Highest g-force for higher solids output
- Adjustable bowl speed via VFD
- Automatic adjustment of differential speed via VFD
- Two motor drive
- Belts for both primary motor and secondary motor
Model | LW300×1200 | LW355×1600 | LW400×1800 | LW450×1800 | LW530×2280 |
Bowl Diameter mm | 300 | 355 | 400 | 450 | 530 |
Bowl Length mm | 1200 | 1600 | 1800 | 1800 | 2280 |
Length to diameter ratio | 1:4 | 1:4.5 | 1:4.5 | 1:4 | 1:4 |
Speed r/min | 4200 | 3800 | 3400 | 3450 | 2700 |
Separation Factor | 3000G | 2868G | 2587G | 3000G | 2150G |
Screw differential r/min | 5-30stepless adjustable | 2-20stepless adjustable | 2-25stepless adjustable | 2-25Stepless adjustable | 3-20Stepless adjustable |
Motor kw | Main11,Vice 4 | Main 15,Vice 5 | Main 22vice7.5 | Main 30 Vice 11 | Main 45 vice 15 |
Driving | Dual motor ,frequency | Dual motor ,frequency | Dual motor ,frequency | Dual motor ,frequency | Dual motor ,frequency |
Noise db(A) | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 |
