Low-cost sand making machine with good gravel particle shape and low investment
The DSMAC sand making machine is unique due to its crushing process. Whereas most other types of crusher use metallic parts to crush rock, the sand making machine uses the rock fed into the machine to crush itself. This autogenously crushing process produces the best-shaped aggregate on the market today.
1. Low Cost Sand making machine Technical Parameter :
Type |
Max feed (mm) |
Power (kw) |
Impeller Speed (r/min) |
Production Capacity(t/h) |
Dimension(mm) |
PCX-600 |
35 |
22~55 |
2000~3000 |
12~30(-0.8mm30%)(-0.8mm60~90%) |
2500*1600*2260 |
PCX-850 |
50 |
90~180 |
1200~2000 |
55~100(-0.8mm30%)(-0.8mm60~90%) |
3900*2160*2770 |
PCX-1050 |
55 |
150~264 |
1000~1700 |
100~160(-0.8mm30%)(-0.8mm60~90%) |
4660*2450*3660 |
PCX-1280 |
60 |
264~440 |
850~1450 |
160~300(-0.8mm30%)(-0.8mm60~90%) |
5600*2950*4000 |
PCX-1400 |
80 |
400~500 |
800~1193 |
200~400(-0.8mm30%)(-0.8mm60~90%) |
5340*2940*3650 |
2. Low Cost Sand making machine Features
- The theory of stone hitting ensures low energy consumption and high crushing efficiency.
- The process of crushing is intense with high crushing efficiency. Presently, this type of sand maker is the most popular in the market.
- The consumption of quick-wear parts is low. The sand maker is designed with the best crushing angle within the cavity and causes little friction with wear-resistant parts.
- The sand making machine is so environmentally-friendly that it causes little noise and pollution when operating. The operating sound is below 75 db and no dust is created.
- Aggregates and sand. The quarry industry has been the traditional home of the DSMAC VSI. VSIs are particularly successful in producing road-base, top dressing chip, concrete and asphalt aggregates, and manufactured sand;
- Industrial minerals. With features such as controlled product grading, preferential crushing, low production costs and the ability to produce finely graded products, the addition of VSI can optimize the performance of most industrial mineral processing installations;
- Mining. High capacity to produce finely graded products such as mill feed, sinter feed or material for heap leach operations, is an ideal machine to replace high cost, inefficient crushing and milling equipment;
- Construction Waste recycling. Recycled materials not only take the form of mineral aggregates for the construction industry, but also glass, slags and other waste products that can be processed and profitably sold. The DSMAC VSI provides the perfect means of treating these materials.
4. To Get Process Benefits of Low Cost Sand making machine
- Lower wear costs per ton. In some cases average wear part lives have increased by 50%. This means less maintenance time and higher crusher availability;
- Highest flakiness/shape index of aggregates produced;
- Crushing ratio easy adjustable as per rotation speed modification (the machine can be quickly tuned to face process needs);
- High capacity (up to 400 TPH). A denser particle population in the chamber will give more effective reduction and improved shape;
- Possibility to re-crush unsold small materials (2-6 mm; 4-8 mm,…) and single fraction round materials (16-32mm,…).
100-150TPH River Stone Crushing Line
Capacity: 100-150TPH
Raw materials: River stone
Max feeding size: 200-250mm
Output size: 0-5mm, 5-15mm, 15-25mm
| NO. | Equipment | Model | Set | Capacity(t/h) | Motor Power(KW) |
| 1 | Apron Feeder | BW1000 | 1 | 60-160 | 15 |
| 2 | Jaw Crusher | PE400*600 | 2 | 30-60 | 30 |
| 3 | Cone Crusher | PYS-B1313 | 1 | 100-200 | 160 |
| 4 | VSI Sand Maker | PCX1280 | 1 | 160-300 | 160 |
| 5 | Sand Washer | XS3600 | 1 | 150-200 | 18.5 |
| 6 | Vibrating Screen | 2YK1840 | 1 | 100-500 | 22 |
| 3YK2460 | 1 | 100-200 | 30 | ||
| 7 | Belt Conveyor | B800*22 | 6 | 100-500 | 7.5 |
5. Low Cost Sand making machine Pictures:
Found in 1997, DSMAC Group is a leading manufacturer of crushing equipment and wear-resistant materials in China. It mainly specializes in producing crushing, feeding and screening equipment, including stone crusher, mobile crusher, and sandstone aggregate production line.
DSMAC mining equipment is widely used in mining, metallurgy, chemical industry, construction waste recycle, building materials, coal industry, etc. Its products have been successfully exported to Malaysia, Turkey, Mongolia, Vietnam, Cameroon, France, Germany, the Middle East and Africa, totally 100 countries and regions.
>Terms of Trade <
1.Payment: 30% advance payment by T/T, 70% balance should be paid off before loading, Western Union, L/C is available.
2. FOB and EXW all are available.
3. Production lead time: 15-45 days.
4. Shipping freight is quoted under your requests.
1. Q: How long does the machine need to be oiled after it begins to work?
A: Generally each 8 hours’ constant working
2. Q: What is the material of the spare parts?
A: High manganese casting steel, National Standard ZGMn13Cr+ Ti or ZGMn18Cr2+Ti
3. Q: What should I do if the discharging granularity becomes bigger after a period of working?
A: Check if the bottom of the tooth plate has been severely worn out, if yes, you need to turn around the tooth plate or adjust the discharging opening size.
4. Q: What should we need to do for if we want to get a best quotation?
A: Hi, if you want to get the correct and exact selection of the model earlier, please help us with following information
1).the capacity (tons per hour)
2).input and output size
3).stone material to be crushed
