Specifications
Construction Waste Mobile Crusher Plant;1.ISO9001:2008 certified & SGS;
2.High flexibility;
3.Easy to operate and collocate.
Construction Waste Plant Mobile Jaw Crusher for sale
(1) Mobile Jaw Crusher information:
The Portable jaw crusher(mobile jaw crushing and screening plant) is the latest rock crushing equipment, widely used in areas with large move-ability, such as metallurgy,chemical industry, building construction, hydroelectic project etc.. User can chooose various disposition form accrding to raw material, handling capacity and requirement of the finished products. Rubber-tyred mobile jaw crushing and screening plant expands the concept of coarse crushing to a large extent.
(2) Mobile Jaw Crusher Technical parameter:
DMP JAW PLANTS |
DMP600 |
DMP750 |
DMP900 |
DMP1060 |
DMP1200 |
|
transport dimension |
Length(mm) |
8600 |
9600 |
11097 |
13300 |
15800 |
Width(mm) |
2520 |
2520 |
3759 |
2900 |
2900 |
|
Height(mm) |
3770 |
3500 |
3500 |
4440 |
4500 |
|
Weight(kg) |
15240 |
22000 |
32270 |
57880 |
98000 |
|
Axle weight(kg) |
10121 |
14500 |
21380 |
38430 |
64000 |
|
King pin weight(kg) |
5110 |
7500 |
10890 |
19450 |
34000 |
|
Jaw crusher |
Model |
PE400*600 |
PE500*750 |
PE600*900 |
PE750*1060 |
PE900*1200 |
Feed opening(mm) |
400*600 |
500*750 |
600*900 |
75*1060 |
90*1200 |
|
Setting range(mm) |
40-100 |
50-100 |
65-180 |
80-180 |
95-225 |
|
Capacity(m3/h) |
10-35 |
25-60 |
30-85 |
70-150 |
100-240 |
|
Feeder |
Model |
GZT0724 |
GZT0724 |
GZT0932Y |
ZSW200 |
ZSW300 |
Feed hopper volume(m3) |
3 |
4 |
7 |
10 |
10 |
|
Hopper width(mm) |
2200 |
2500 |
3000 |
3000 |
3000 |
|
Belt conveyor |
Model |
B650*6 |
B800*7 |
B1000*8 |
B1000*11 |
B1200*13 |
(3) Characteristics of Mobile Jaw Crusher
- High effective performance, big crushing ratio, and strong driving force.
- Integration of truck-mounted motor and electronic cabinet box.
- Vibrating feeder, screen, jaw crusher, cone crusher and vertical crusher are integrated together.
- Integrated installation of belts, screen and crusher.
- Quick installation.
- Convenient highway transportation and ground detection.
(4) Mobile Jaw Crusher Application:
The portable jaw crusher(mobile jaw crushing and screening plant) is suitable to crush granite,black trap rock,river gravel,quartzite,blast furnaces slag,zinc ore lime,copper ore,iron ore,stone, mangenese ore,bauxite ore,fero alloys,dolomine,feldspar,granite,basalt,rail ballast etc.
(5) Working principle of Mobile Jaw Crusher
- The portable jaw crusher(mobile jaw crushing and screening plant) includes Hopper,Vibrating Feeder,Jaw Crusher,Semi-trailer Chassis and other supporting parts. The material is fed into the hopper by the loader. Vibrating Feeder can prescreen the material during its working process,and feed bigger materials into Jaw Crusher for primary crushing process. Then crushed material will be carried out by the belt conveyor.
- The Portable jaw crusher(mobile jaw crushing and screening plant) has the advantage of reasonable match,unobstructed material discharge,reliable run,convenient operation,high efficiency and energy conservation.The good mobility can make it move in and between different quarries.It can also work with other plants to meet different requirements of customers.
