Specifications
strongpoints like large conveying amount, simple structure, easy maintenance, high standardization degree etcBelt conveyer is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force.
The belt conveyer is advanced and simple in structure, easy to maintain. Its transfer capacity is high, transfer distance is long. They are widely used in mining, metallurgical and coal industry to transfer sandy or lump material, or packaged material. In many situation, it Is a very important component of nonstandard machinery.
The belt conveyers produced by BREAK-DAY can be operated in the circumstance temperature range from -20°C to +40°C. The temperature of transferred material by this belt conveyer should be lower than 50°C.
Belt Width(mm) |
Belt Length (m) / Power (KW) |
Belt Speed(m/s) |
Capacity(t/h) |
||
B400 |
≤12/1.5 |
12~20/2.2~4 |
20~25/3.5~7.5 |
1.3~1.6 |
30~60 |
B500 |
≤12/3 |
12~20/4~5.5 |
20-30/ 5.5~7.5 |
1.3~1.6 |
40~80 |
B650 |
≤12/4 |
12~20/5.5 |
20~30/7.5~11 |
1.3~1.6 |
80~120 |
B800 |
≤6/4 |
6~15/5.5 |
15~30/7.5~15 |
1.3~1.6 |
120~200 |
B1000 |
≤10/5.5 |
10~20/7.5~11 |
20~40/11~12 |
1.3~2.0 |
200~320 |
B1200 |
≤10/7.5 |
10~20/11 |
20~40/15~30 |
1.3~2.0 |
320~500 |
