2 x 15 Brass Screw Terminal Block2 x 15 Brass Screw Terminal Block
Specifications
2 x 15 brass screw terminal block
1.Small Order Accept
2.High Quality & design
3.CE Certificate
4.OEM service
Application:
Supplied with insulated back plated and transparent protective front cover,self-extinguishing 960
mounting methods
on rail
on plate with 2 screw
When installing under a front plate, a blanking plate can be clipped onto the front plate
Material
1.PA Polyamide 66,94-2 grade,inflaming retarding
2.Working Temperature: -30 °C to 110 °C
3.Brass screw: iron plated zinc
4.Voltage:250V-450V
5.Color: blue and transparent white
Item No. | Spec. | Rated current ( A ) | Rated voltage ( V ) | L1 | L2 | H | W | Max. section | Hole. Qty | Plastic Setting |
W×H | mm | |||||||||
207 | 6.5 x 12 | 125A | 500V | 67 | 48 | 50 | 45 | 35mm2 | 2 x 7 | PA |
211 | 100 | 86 | 50 | 45 | 2 x 11 | |||||
215 | 134 | 118 | 50 | 45 | 2 x 15 | |||||
407 | 67 | 48 | 50 | 90 | 4 x 7 | |||||
411 | 100 | 86 | 50 | 90 | 4 x 11 | |||||
415 | 134 | 118 | 50 | 90 | 4 x 15 | |||||
413 | 8 x 17 | 160A | 180 | 168 | 73 | 138 | 50mm2 | 4 x 13 | ||
