Home > Products > Circuit Breaker > Motor Protective Circuit Breaker GV2-M GV2ME
Motor Protective Circuit Breaker GV2-M GV2ME
Negotiable
/ Piece
20 Pieces(Min.Order)
- 5000 Piece / Pieces per Month
- NINGBO SHANGHAI ETC.
- T/T Credit Card
You May Like
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | KASAN | Model Number: | GV2ME |
| Type: | Mini | Poles Number: | Other, all have |
Product Description
Specifications
Motor Protective Circuit Breaker GV2-M GV2ME2)With CE Attestation
3)The Mos
Motor Protectiove Circuit Breaker GV2-M GV2ME
GV series motor protection circuit breaker are mainly used for the overload and short circuit protection of the motor in AC 50/60Hz, up to 660V, 0.1-80A power circuit, as a full-voltage starter to start and cut off the motor, under the AC3 load or for the overload and short circuit protection of the circuit and power equipment in the power distribution network.
| Specification | |||||||
| Type | Stand power rating of 3-phase motors 50/60Hz in category AC-3 | Setting range | |||||
| 220V | 380V | 415V | 440V | 500V | 660V | ||
| kW | kW | kW | kW | kW | kW | ||
| GV2-M01/RS01 | 0.1-0.16 | ||||||
| GV2-M02/RS02 | 0.16-0.25 | ||||||
| GV2-M03/RS03 | 0.25-0.4 | ||||||
| GV2-M04/RS04 | 0.37 | 0.4-0.63 | |||||
| GV2-M05/RS05 | 0.37 | 0.37 | 0.55 | 0.63-1 | |||
| GV2-M06/RS06 | 0.37 | 0.55 | 0.75 | 1.1 | 1-1.6 | ||
| GV2-M07/RS07 | 0.37 | 0.75 | 0.75 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| GV2-M08/RS08 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| GV2-M10/RS10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4-6.3 |
| GV2-M14/RS14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6-10 |
| GV2-M16/RS16 | 3 | 5.5 | 5.5 | 7.5 | 7.5 | 9 | 9-14 |
| GV2-M20/RS20 | 4 | 7.5 | 9 | 9 | 9 | 11 | 13-18 |
| GV2-M21/RS21 | 5.5 | 11 | 11 | 11 | 11 | 15 | 17-23 |
| GV2-M22/RS22 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 20-25 |
| GV2-M32/RS32 | 7.5 | 15 | 15 | 15 | 18.5 | 26 | 24-32 |
| GV3-M06 | 0.37 | 0.55 | 0.75 | 1.1 | 1-1.6 | ||
| GV3-M07 | 0.37 | 0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 1.6-2.5 |
| GV3-M08 | 0.75 | 1.5 | 1.5 | 1.5 | 2.2 | 3 | 2.5-4 |
| GV3-M10 | 1.1 | 2.2 | 2.2 | 3 | 3.7 | 4 | 4-6 |
| GV3-M14 | 2.2 | 4 | 4 | 4 | 5.5 | 7.5 | 6-10 |
| GV3-M20 | 4 | 7.5 | 7.5 | 7.5 | 10 | 11 | 10-16 |
| GV3-M25 | 5.5 | 11 | 11 | 11 | 15 | 18.5 | 16-25 |
| GV3-M40 | 11 | 18.5 | 18.5 | 22 | 25 | 33 | 25-40 |
| GV3-M63 | 15 | 30 | 33 | 33 | 40 | 55 | 40-63 |
| GV3-M80 | 22 | 40 | 45 | 45 | 55 | 63 | 56-80 |
