Help CenterAutomatic High Speed Plastic Blister Packaging Sealing Machines Blister
Related Products
-
Papercard Mutifunctional Packaging Machine for Battery/toothbrush/pen/stationeryUS$ 19,000 - 25,000MOQ: 1 Set -
Toothbrush Manufacturing Machine,Automatic Blister Packing MachineUS$ 17,000 - 25,000MOQ: 1 Set
-
Blister and Paper Card Hot Seal Package Machine for StationeryUS$ 18,000 - 45,000MOQ: 1 Set
-
Fully Automatic Lipstick Machine ( PVC+Card )US$ 20,000 - 60,000MOQ: 1 Set
-
Top Sale! Card and PVC Blister Sealing Tooth Brush Packaging MachineUS$ 17,000 - 27,000MOQ: 1 Set
Specifications
sealing machines blister1.Save labor
2.Save material
3.Easy Changeover
4.Double program
sealing machines blister
Usuage:
Suitable for packaging with paper and plastic in the industrial of hardware, medical equipment, toys, battery, electronic products, auto parts, cosmetic ,rubber products, dinnerware, kitchen ware.
For example :
the injection, syringe, toy car, flashlight, spark plug, toothbrush , lipstick ,facial mask, chopsticks, shaver, correction fluid , ball pen, medicine and so on.
Working process:
Placed PVC roll——PVC heating——Plastic blister trays forming——Servo traction——PVC plastic punching——PVC edge material collecting——transferring into sealing recycle molding——Manual feeding/(Battery add feeder)——Automatic paper card placing——blister & card heat sealing——Products output
Main Technical Parameter
Model |
DZP-500B |
Punching frequency |
10-28 times/min |
Travel range |
40-130mm |
Air pressure |
0.5-0.8Mpa |
Air flow |
≥0.5m³/min |
Total power |
380V 50Hz 7KW |
Main motor power |
1.5KW |
Maximum specification of PVC |
480×130mm (design according to customer requirements is also available) |
Maximum specification of paperboard |
500×150mm (design according to customer requirements is also available) |
Outline dimensions |
3750×920×1650mm(L×W×H) |
Machine weight |
2100Kg |
Some Part of this Machine:
Pre-heating station
Blister forming station
Servo traction (Mechanical hand picking blisters into sealing molds)
Paper and plastic sealing station
Samples:
We hope to have the opportunity to invite you join our customer team. We will do our best to serve you!
