Specifications
jam pack1. CE, GMP
2. PLC control
3.Automatic feeding
4.Small ,low price
Liquid blister packing machine for butter /honey/jam pack
Feature:
1. This machine is suitable for packing the liquid like chocolate, butter ,honey and jam etc.
2. PLC Touch Screen control system
3. Printed mark controller (GC register)
4.All material contact parts are in S.S. 316 L. The main body of the machine is fabricated out of SS 304.
5. The printing Net weight, Lot number, Prod. date and Exp. date are by steel character on the bottom of every blister (package)
6.Safety cover while open the machine and stop it as the CE required (sealing/cutting part), aluminum alloy and organic glass as material
7. This machine can be linked to produce with boxing machine and pillow packing machine
Working process:
PVC roll——PVC heating——PVC forming —— Automatic cooling —— Servo traction—— Automatic liquid feeding —— PE/ALU foil/paper card sealing —— Printing batch —— Cutting —— Products output
Main Technical Parameter
Equipment model and specification |
JDPP 140P |
Machine weight |
Machine weight:1100Kg tank weight: 60 Kg |
Overall dimension |
Machine size: 2300 x820x1900mm Tank size: 850x500x500 mm |
Total Power |
4 Kw |
Zero air pressure(MPA) |
0.5-0.7 |
Power supply |
3 phase , 380 VAC , 50 Hz |
Punch frequency |
15 ~ 25 time/min |
Packing efficiency |
3,600 ~ 6,000 plate/h |
Max. forming area and depth |
140 x 100 x 18mm |
Adjustable range of stroke |
30 ~ 110 mm |
Air compressor |
≥ 0.22 m3/min (self-prepared) |
Specification function |
Automatic feeding system, Emergency stop function: when an emergency stop is pressed. the machine stops safety and can only be restarted by resetting the machine controls, Print registration. |
Control system |
PLC, Touch screen, with communication port. |
Criterion |
Conform to GMP standard CE certificate |
Some Part of this Machine:
Samples:
