Help CenterSJ-45-ICRGB 45mm Rgb Pixel Point Led
Related Products
Specifications
Digital 45mm pixel led1.DC12V;0.72W/pcs
2.WS2801 IC Individual addressable
3.Waterproof IP66
4.SD controller,DMX512
12v Waterproof pixel rgb led string 45mm 3 smd5050 leds
Description:
ws2801 lpd6803 45mm pixel dot led, 3leds, 6leds.
1.RGB Pixels are digitally-controllable light so you can set to any color or animate
2.The pixels are connected by a 4-conductor cable.+12V(Red),Ground(Yellow),Data(Green),Clock(Blue).Or we can tailor-make the color of cable for you .Data is shifted down from one pixel to the next so that you can easliy cut the strand or attach more onto the end
3.Sold by strand,each strand has 20 pixels in series. Each strand has two 4-pin connectors so you can connect multiple strands in a row,as many as you wish,just watch for how much current they want
4. Relative Controller: T-1000S controller support WS2801; when use DMX decorder, can connect to DMX system
5. Support online control
6.Can be used as flexible led display screen to show image and video
Features:
1)programmable by software
2)3 pcs RGB SMD leds
3)20pcs per string,8cm space between each Pixel
4)customized wire length is available
Specification:
Model NO. |
SJ-45ICRGB |
Diameter |
45mm |
Power Consumption |
0.72W, 1.44W |
Work Voltage |
DC12V, DC24V |
Viewing Angle |
≥140 |
LED Quantity |
3pcs, 6pcs |
LED Type |
SMD5050RGB |
Emitting Color |
Full color(ICRGB) |
IC Type |
WS2801&LPD6803 |
Waterproof Rating |
IP66 |
Working Temperature |
-40-55°C |
Lifespan |
50,000hrs |
Certification |
CE&RoHS |
Warranty |
2 years |
Application:
1.Channel letter
2. Advertisement sign
3. Advertisement light box and billboard
4. Widely used in LOGO
5.Decorative lights for holiday, event ,show, exhibition
6.DIY light for home use
7.Christmas decoration
Picture details:
45mm milky cover pixel led waterproof IP66
20pcs/string, 2 4pin male and female connectors on each end of the string.
Controller: DMX controller & decoder & SD controller & arduino controller, t-1000S
Effect: every pixel led with ws2801 or lpd8806 control, can change color individually.
Package: 20pcs/string 8cm lead in cable wire, 100pcs/An-ti static bag 1000pcs/carton.
