Home > Lights & Lighting > LED Outdoor Lighting > LED Point Light > 30mm WS2801 LED Pixel Light DC12V (RGB)

30mm WS2801 LED Pixel Light DC12V (RGB)

Name: 30mm WS2801 LED Pixel Light DC12V (RGB)
Brand: iPixelLED
SKU: 134756949
Availability: InStock

30mm WS2801 LED Pixel Light DC12V (RGB) thumbnail-1

30mm WS2801 LED Pixel Light DC12V (RGB) photo-1

US$ 0.1 - 1.5 MOQ: 1 Piece

Key Specifications

Get Latest Price

LED Light Source:

Epistar

Input Voltage(V):

Lamp Power:

0.72

Contact Supplier Request Quote Chat Now

Shenzhen Shiji Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Yantian shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source Epistar

Input Voltage(V) 12

Lamp Power 0.72

Lamp Luminous Flux(lm) 30

Lamp Luminous Efficiency(lm/w) 40

Color Temperature(CCT) Other, RGB

Working Temperature(℃) -30, 40

Working Lifetime(Hour) 50000

Lamp Body Material PC

IP Rating IP65

Certification CE

Emitting Color Changeable

Place of Origin Guangdong, China

Brand Name iPixelLED

Model Number SJ-30ICRGB

Product Description

Features
RGB Pixels are digitally-controllable lights (addressable)
you can set to any color, or animate by microcontroller
There are four flanges molded in so that you can 'push' them
into a 32mm drill hole in any material up to 1.5mm/0.06" thick
but it have to put some silicon glue on the back side of the ears makes it more strong

you may also install it on the wall and hold it by screw
They're typically used to make outdoor signs
The pixels are 20pcs per strand connected by 4Pin wire :
Data is shifted down from one pixel to the next so that you can easily
connect to the strand or attach more onto the end
(we also could do custom cable length )

P/N

Size/mm

LED

IC/Qty

LED /Module

Luminous(MCD)

View Angle

Voltage

Wattage

IP Rate

SJ-30ICRGB

RGB5050

WS2801

R:2100,G:5100

B:1800

140

DC12V

0.72W/PCS

20 LED per string there are a pair of 4Pin JST SM connector
and each of them on end string,the connector is non-waterproof
there are 2 version different Body,frosted or Clear

Our Services

Trade term	EXW, FOB
Payment	T/T, Western Union
MOQ	1 pcs
Package	Exporting carton, flycase, wooden case
Leading time	Sample order: 1-3 days Big order: 4-15 days
OEM	OEM is acceptable
Warranty	1 year
After service	If there is the problem with the product, firstly you need send the picture or the video to us, then let us make sure what’s problem about the product, we will try our best to help you .if the problem can use the part to solve ,we will offer you the replacement for free Within 1 year.

Company Information

Shiji Lighting Co., Ltd was founded in 2010 and since then we have developed the brand iPixel LED. Shiji Lighting is an established firm specializing in the research and engineering of various LED products. We have a well rounded sales team consisting of members ages 26 to 45. Senior teammates have conducted business with companies from all over the world and have a thorough understanding of clients' differing needs. Therefore, they are able to provide much guidance and support to our junior members. At Shiji Lighting we are striving to become the most sought out distributor of pixel LEDs. To acheive this we are developing products and providing services that enable us to work with you for many years to come. Please find below our range of products. We welcome you to send us inquiries about our standard products and we also accept OEM requests. We look forward to hearing from you soon.

FAQ

1.Why choose us?

(1).We are the manufacturer and we produce economic products.
(2). Our All stage lights must pass strict quality control procedures(CE and RoHs).
(3). Each product has been repeated and strict tests before shipment.
(4).We can produce the products depend on clients' requiremet.

2. Any Guarantee?

We provide 1-year limited warranty

3.Paymen&Delivery?
We accept T/T,Western Union and Paypal for the payment.
As normal,we will delivery within 7 workdays after receive the payment.

4. Whether the lights are the same as the pictures?
The pictures in the link you see are all taken from really products, but they may be

very slightly different from really products due to the factors such as cameras used,

environmental light and even computers etc.
