Specifications
waterproof 45mm rgb dot light pixel for decoration1.ucs1903 IC
2.Diameter: 45mm
3.CE, RoHS
waterproof 45mm rgb dot light pixel for decoration
Features:
RGB Pixels are digitally-controllable lights (addressable)
you can set to any color, or animate by microcontroller
There are four flanges molded in so that you can 'push' them
into a 32mm drill hole in any material up to 1.5mm/0.06" thick
but it have to put some silicon glue on the back side of the ears makes it more strong
you may also install it on the wall and hold it by screw
They're typically used to make outdoor signs
The pixels are 20pcs per strand connected by 4Pin wire
Data is shifted down from one pixel to the next so that you can easily
connect to the strand or attach more onto the end
(we also could do custom cable length )
| P/N | Size/mm | LED | IC/Qty | LED /Module | Luminous(MCD) | View Angle | Voltage | Wattage | IP Rate |
| SJ-30ICRGB | 30 | RGB5050 | WS2801 | 3 |
R:2100,G:5100 B:1800 |
140 | DC12V | 0.72W/PCS | 65 |
and each of them on end string,the connector is non-waterproof
there are 2 version different Body,frosted or Clear
Our compamy:
ShenZhen Shiji Lighting Co.,Ltd established high-tech firm specialized in the research, development, engineering, and marketing of LED based lighting solutions. We have professional engineers always staying at the forefront of LED technology. We're especially well-placed in the field of sign lighting solutions and interior lighting We're Located in ShenZhen south of China, near ShenZhen Airport and HK with convenient transportation Our product range is as follows:
1.5050&3528 LED module Backlight for Channel Letters & signage
2. RGB LED pixel light & LED string light
3. LED flexible strips & LED rigid bar for Decorative Lighting
4. High Power LED spot light
5.LED flood light
6.LED ceiling light
Clients are welcome to buy our standard products, or send us OEM requests. You will be impressed by our quality and service.
If any question,please feel free to contact us.Thank you.
