<h2>dc5v 8 x 32 256pcs apa102c addressable flexible led madrix panels</h2>
Features and specifications:
- Individually addressable RGB LEDs (8*32 LEDs)
- 24-bit color control (8-bit PWM per channel); 16.8 million colors per pixel
- Additional color-independent brightness control (5-bit PWM); 32 brightness steps per pixel
- SPI control interface, APA102C IC built inside RGB 5050 led lamp
- dc5 V operating voltage
- Each LED Matrix draws approximately 8A at full brightness
- 80MM X 320MM, pitch distance :10mm
- Flexible,bendable IP20 rating
- Black strip color
- Power/data connectors on both strip ends for easy chaining
Part Number |
Emitting Color |
Signal |
IP |
IC |
|
SJ-8 X 32 APA102C |
Full color |
SPI |
IP20 |
APA102C |
|
Beam angle |
140 deg. |
||||
Light source |
APA102 |
||||
Pixel resolution |
80*320mm |
||||
Operating voltage |
DC5V |
||||
Consumption watts |
19±1W |
||||
Pixel pitch(mm) |
10mm |
||||
Entire piece LED quantity |
256 pcs |
||||
Lumen per LED(mcd) |
R:500-65 G:370-530 B:120-165 |
||||
Key features of APA102C Flexible led panels:
1. 8 x 32 PCS APA102C led pixel madrix is used the 2 data wire-DAT and CLK, so it can be faster than ws2812b protocol and there's no specific timing required. it's also have much higher PWM refresh rates.
2. This Matrix panel is made of flexible PCB material,Non-waterproof ,for indoor use only, 1 Ounce copper PCB and black pcb color you can also connect each matrix together to make them as large as a P10 LED screen, make sure gave them enough Power , each matrix 256 pcs LEDs request at least 12.5A.
3. These matrix comes in 1pcs per bag, on the back side, soldered a pair of 4-pin JST SM connector, it is easy to connect the next matrix
4. APA102C LED matrix panel uses a much higher PWM frequency for controlling each colro channel --20 KHz PWM rate , comared to 400 Hz on the WS2812B. As a result, the APA102c led matrix transmission signal speed much faster than the ws2812b led matrixs.
5. In addition, the APA102c LED matrix panel proides a 5-bit (32 level) color- brightness adjustment
6. for this type of panels, we also have 8x 8, and 16 x 16 pcs APA102C madrix panels.
Product images:
8 x 8 APA102C flexible rgb led madrix panels:
16 x16 pcs APA102C flexible rgb led madrix panels:
