256led Pixel Display Addressable Black Pcb 8x32 Pixels Wholesale IC2811

FOB Price

US$ 5 - 20 / Meter

1 Meter(Min. Order)

Port Shenzhen yantian
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	Epistar chip	Type	Flex LED Strips
Input Voltage(V)	DC5V	Lamp Power	61.44W
Color Temperature(CCT)	pixel	Working Temperature(℃)	-40, 40
Working Lifetime(Hour)	50000.00	Lamp Body Material	Other, Epistar chip
Certification	CE	Emitting Color	Changeable
Place of Origin	Guangdong, China	Brand Name	SJ/IPIXEL LED
Model Number	SJ-0832-2812B

Product Description

256led pixel display addressable black pcb 8x32 pixels wholesale IC2811

Part number	Size:mm	LED Quanlity	Voltage(V)	Pixel	LED	Power(w)	Viewangle	MCD Per Matrix	IP
SJ-832WS2812	80*320	256PCS	5	10mm	WS2812B	75(MAX)	140°	R:99840 G:168960 B:51200	IP20
SJ-1616WS2812	160*160	256PCS	5	10mm	WS2812B	75(MAX)	140°	R:99840 G:168960 B:51200	IP20
SJ-0808WS2812	80*80	64PCS	5	10mm	WS2812B	19(MAX)	140°	R:24960 G:42240 B:12800	IP20

This pixel pcb WS2812B flexible LED matrix is a great way to add an impressive amount

of color while still being able to individually control each LED.

You can create animations, games, or even incorporate them into a fun e-textiles project. On top of all that,

thanks to its flexible backing, this LED Matrix can be bent and bowed to fit onto almost any curvy surface.

These panels require a 5V low voltage input for power which needs to be able to source a good amount of current

– up to 5A in most uses (15A if all LEDs are set to bright white, which is NOT recommended).

Attached to each flexible LED matrix are two 3-pin JST SM connectors and two sets of bare power cables (input / output), which provide you connections for DC5V+, COM-, DAT, and GND. Needless to say, if you are looking for

a large panel of addressable LEDs to fit the contours of almost any surface you’ve come to the right place.

Note: Repeated / Over bending may significantly reduce the structural integrity of the flexible panel. It is advisable when

bending it over curved surfaces to not be too rough with this product as you may damage LED traces or the panel itself.

Control System:

1. Offline control: SJ-T-1000G, SJ-8000G for off-line working, can control max 2048 Pixels, 8192 Pixels.

2. Online control: SJ-T-200K, 300K for on-line working, can control max 4096,8192 pixels.

3. Compatible with Arduino, DMX 512.

CONNECTION:
1) Signal wire: DC+, DAT, GND
2) DC+ and GND connect to power supplier;DAT and GND connect to controller
3) Relative Controller: SPI controller support sk6812; when use DMX decorder, can connect to DMX system
4) Support online control

Non-waterproof use for indoor decoration

3 Pin Male and female Connector on each endside, easy for connect.

Controller: DMX controller & decoder & SD controller & arduino controller

Effect: Change color individually and pixel addressable full color.

Application: flexible LED dispaly, LED curtain. Indoor project.
