360degree emitting 50mm full color ball led pixel module node

Specifications

50mm DMX control led pixel point light
1.DC24V.1.44W/pcs
2.DMX ws2801 chip
3. 6 pcs SMD5050
4.double side, 4pin connect

dmx 360 degree Madrix 3D effect 50mm led ball point light



Description:

1.Constant current driver is designed on the dmx led ball, which can contribute lots to protect lamp's life.

2.50mm diameteer balls with white opaque diffuser giving 360 degree viewing, pitch customized.

3.DMX address manually

4.Full speed video and graphics, 3D effect

5.Environment friendly, no harsh glare and buzzing noise, no flicker.

6.Integrates with Phantom and Chimer.

7.DMX signal is in parallel connection, avoiding all lights influenced by the failure of one light in serial connection

8.High-brightness LED chips, clear and pleasant light beam, bright and non-glare

9.With DMX controller, it can achieve color fading, skipping, scanning, chasing, and play flash and video, etc.

10. 360 degree DMX led pixel ball light



Specification:

Products Name	360 degree DMX led pixel ball light
Model NO.	SJ-50B-2801 /  SJ-50-DMX
Power Consumption	1.44W
Work Voltage	DC24V & 12V
protocl	DMX 512 & ws2801
LED Qty	6 pcs SMD5050RGB
Diameter	50mm
Beam Angle	360 degree with white cover, 3D view
Address setting	Manually with the address coder
Protocl	DMX 512
Pitch	200mm or customized
Control load	170 pixels ( 512 channels ) per output
Warranty	2 years



Application

-Stage video elements for intimate or large concert productions

-Interior design for clubs, museums,themed enviroments

-Exhibitions stands

-Television awards and game shows

-Video Art projects



Picture:  double-side pcb 6pcs smd5050 with one ws2801 IC, 50mm pixel led ball light







 each ball change color individually, 20pcs/string, pixel pitch 20cm.







With male and female 4pin connector on both end of string,

use T-connector to connect ball strings and power supply.







appication: used for curtain, video, flash etc.,

with madrix software & DMX artnet controller & SD controller,

realize  3D effect show.
