Specifications
50mm DMX control led pixel point light1.DC24V.1.44W/pcs
2.DMX ws2801 chip
3. 6 pcs SMD5050
4.double side, 4pin connect
dmx 360 degree Madrix 3D effect 50mm led ball point light
Description:
1.Constant current driver is designed on the dmx led ball, which can contribute lots to protect lamp's life.
2.50mm diameteer balls with white opaque diffuser giving 360 degree viewing, pitch customized.
3.DMX address manually
4.Full speed video and graphics, 3D effect
5.Environment friendly, no harsh glare and buzzing noise, no flicker.
6.Integrates with Phantom and Chimer.
7.DMX signal is in parallel connection, avoiding all lights influenced by the failure of one light in serial connection
8.High-brightness LED chips, clear and pleasant light beam, bright and non-glare
9.With DMX controller, it can achieve color fading, skipping, scanning, chasing, and play flash and video, etc.
10. 360 degree DMX led pixel ball light
Specification:
Products Name |
360 degree DMX led pixel ball light |
Model NO. |
SJ-50B-2801 / SJ-50-DMX |
Power Consumption |
1.44W |
Work Voltage |
DC24V & 12V |
protocl |
DMX 512 & ws2801 |
LED Qty |
6 pcs SMD5050RGB |
Diameter |
50mm |
Beam Angle |
360 degree with white cover, 3D view |
Address setting |
Manually with the address coder |
Protocl |
DMX 512 |
Pitch |
200mm or customized |
Control load |
170 pixels ( 512 channels ) per output |
Warranty |
2 years |
Application
-Stage video elements for intimate or large concert productions
-Interior design for clubs, museums,themed enviroments
-Exhibitions stands
-Television awards and game shows
-Video Art projects
Picture: double-side pcb 6pcs smd5050 with one ws2801 IC, 50mm pixel led ball light
each ball change color individually, 20pcs/string, pixel pitch 20cm.
With male and female 4pin connector on both end of string,
use T-connector to connect ball strings and power supply.
appication: used for curtain, video, flash etc.,
with madrix software & DMX artnet controller & SD controller,
realize 3D effect show.
