dmx arduino control ws2801 3leds 6leds smd5050 50mm diameter pixel led dot light waterproof IP66
- 10000 Piece / Pieces per Month
- shenzhen yantian
- T/T L/C D/P D/A Credit Card PayPal
- led pixel light dmx512 rgb ip66 outdoor waterproof
- DC12V/15V 3LEDs RGB LED Module Pixel Light Outdoor Advertising Display Digital Lamp
- 6xrgb+12xw LED RGB Module Pixel Light TV Outdoor Advertising Display Digital Point Light
- China funfair amusement ride light e14 turbo led
- Aglare classic E14 SMD5050 replacement rgb pixel led amusement lamp
- Color changing DC24V 5050SMD programmable rgb led pixel led farground lights
Product Details
LED Light Source: | smd5050 | Input Voltage(V): | 12V | Lamp Power: | 1.44 |
Color Temperature(CCT): | Other, pixel | Working Temperature(℃): | -30, 50 | Working Lifetime(Hour): | 50000 |
Lamp Body Material: | Copper | IP Rating: | IP66 | Certification: | CE |
Emitting Color: | Changeable | Place of Origin: | Guangdong, China | Brand Name: | SJ / Ipixel |
Model Number: | SJ-50-ICRGB |
Product Description
dmx arduino ws2801 3leds 6leds smd5050 50mm diameter pixel led dot light waterproof IP66
Description:
ws2801 smd rgb 50mm pixel led
1.DC12V,0.72W/pcs,1.44W/PCS
2.3pcs or 6pcs SMD 5050 LEDs per dot module
3.SD card controller, dmx512, artnet controller Individually control,Waterproof IP66
4.This product could be linked up to 20pcs/string.
5.Can achieve effects of full-color running water,chasing and scanning.Depending on the different installation methods may compose different dynamic effect of different color's character and design.
6. The spacing between lamps can be chose according to the building height.
7. The pixels are connected by 4-connector cable.+12V(Red),Ground(Yellow),Data(Green),Clock(Blue). Or we can tailor-make the color of cable for you .Data is shifted down from one pixel to the next so that you can easliy cut the strand or attach more onto the end.
Specification:
Products Name | 50mm RGB pixel led dot light |
Model NO. | SJ-50ICRGB |
Power Consumption | 0.72W,1.44W |
Work Voltage | DC12V |
Beam Angle | ≥140 |
LED Quantity | 3pcs or 6pcs SMD5050RGB |
Color | Full color(ICRGB), changeable, pixel, digital, dream color, magic color |
IC chip | WS2801, lpd6803 |
Waterproof Grade | IP65, IP66, IP67 |
Work Temperature | -40-60°C |
Life-span | 50,000H |
Certificate | CE&RoHS |
Warranty | 2 years |
Application:
1.Outdoor signs.
2.Christmas lighting solutions
3.Advertisement light box and billboard
4.Widely used in large-size LOGO
5.Decorative lights for holiday, event ,show, exhibition
6.DIY light for home use
7.Exposed luminous characters
8.Painted screen etc.
Picture details:
3leds 6leds available 50mm milky cover pixel led waterproof IP66.
Each led use 4 screws to mounting on board or wall.
20pcs/string, 2pcs 4pin male and female connectors on each end of the string.
This connector also can be made in waterproof, then need T-connector to power supply.
Controller: DMX controller & decoder & SD controller & arduino controller, t-1000S.
Effect: every pixel led with ws2801 or lpd6803 control, can change color individually.
Services:
1.Reply your inquiry in 24 hours
2.Experienced staffs answer all your questions in fluent English
3.Customized design is available.OEM&ODM are welcomed
4.Exclusive and unique solution can provide to customer by our well trained and professional technicians
5.Special discount and protection of sales area provided to our distributor
Shipment:
1.Goods will be delivered within 3-5 working days after the payment received
2.We ship item via DHL, Fedex,UPS,Door to Door service express or air and sea.
Warranty:
1. All products we sell are in good quality and have been tested before they are shipped out
2. We offer 2 years Warranty
Certification :CE&Rohs
ShenZhen Shiji Lighting Co.,Ltd established high-tech firm specialized in the research, development, engineering, and marketing of LED based lighting solutions. We have professional engineers always staying at the forefront of LED technology. We're especially well-placed in the field of sign lighting solutions and interior lighting We're Located in ShenZhen south of China, near ShenZhen Airport and HK with convenient transportation Our product range is as follows:
1.5050&3528 LED module Backlight for Channel Letters & signage
2. RGB LED pixel light & LED string light
3. LED flexible strips & LED rigid bar for Decorative Lighting
4. High Power LED spot light
5.LED flood light
6.LED ceiling light
Clients are welcome to buy our standard products, or send us OEM requests. You will be impressed by our quality and service.
If any question,please feel free to contact us.Thank you.
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Need about 3-5 days, mass production time needs 1-2 weeks for order quantity more than.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
