Introduction:
Superfine surface to take roll slitter QFJ Series is a high-precision, high sensitivity longitudinal slitting equipment, slitting speed of any governor in the 0-220 m / min, with a frequency control motor, unwinding constant tension brake, automatic counting, automatic shutdown, self-corrective optoelectronic devices; winding two magnetic powder clutch host linkage control (pneumatic) center take-up contact with the surface and use biaxial staggered winding owned seams . The device is suitable for paper, BOPP, PET, PE, PVC, aluminum foil, the use of insulating materials decile cut.
Features:
1, the machine uses the center winding and surface contact rewinding
2, equipped with photoelectric automatic correction device, constant tension magnetic brake, clutch device
3, equipped with automatic meter, automatic stopping device
4, the host VVVF
| maximum material width | 700mm |
| largest raw material diameter | Φ600mm |
| rewinding paper core diameter | Φ25mm Φ76mm |
| winding diameter of | Φ450mm |
| Maximum cutting width | 700mm |
| minimum slitting width | 5mm (slitting) |
| mechanical speed | 0-220 m / min (VVVF) |
| motor power | 4kw |
| total power | 6.5kw |
| Dimensions | 1800x1800x1200mm |
| machine weight | 2200kg |
Precision high marks cut the narrow, winding end formation. 5MM between 50-80 meters in one minute, the the Larsson film (high pressure feed) stickers, paper, aluminum foil
