Horizontal Type Slitting Machine or Kraft Paper Slitting Machine Baking Paper Slitting Machine

Name: Horizontal Type Slitting Machine or Kraft Paper Slitting Machine Baking Paper Slitting Machine
Brand: Dongchen
SKU: 134730341

US$ 1,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Slitting Rewinder

Computerized:

Yes

Ruian Dongchen Packaging Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Slitting Rewinder

Computerized Yes

Place of Origin Zhejiang, China

Brand Name Dongchen

Model Number DC-1100

Voltage 380V

Power(W) 5.5KW

Dimension(L*W*H) 2500x1850x1700

Weight 1800kg

Certification CE Certificate

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

High Quality Silicon Paper Slitting Machine or Kraft paper Slitting Machine Baking Paper Slitting Machine

Application

This machine is suitable for BOPP,PET,PE,PVC,Aluminum foil,Paper,insulation material vermicelli.

1. Auto count meter,Alarming and so on.

2. Applying A,B air shafts in wind,easy operation.

3. EPC guiding in the unwind,more smooth for wind,even disorder materials.

4. Disk cutting system

5. 3” air shaft 3pcs


Mian Technical

Model	QFJ-A700	QFJ-A1100	QFJ-A1300
Max.width of finished product	700mm	1100mm	1300mm
Max.diameter of raw material	Φ1000	Φ1000	Φ1000
Diameter of finished product coil	Φ450	Φ600	Φ600
Speed of parting cut	0-180m/min	0-180m/min	0-180m/min
Power of electric machine	3kw	4.5kw	5.5kw
Weight	1800kg	2200kg	2500kg
Overall dimension	1800x1800x1200mm	1800x1800x1200mm	1800x1800x1200mm
