CORONA TREATER
Performance:
Owing to series of HW corona treatments adopted the best international source technology, this is resonant type switch power technology, and it had a new appearance in the filed of film surface treatment technology to the customers. It had excellent characteristics, ideal of film surface treatment newly aspect design and high reliability. It can compare with the same advanced product of foreign.
MAIN PARAMETER:
|
HW2001 |
HW2002 |
HW2003 |
HW2004 |
||||||
Input voltage, frequency |
Single phase AC220v(+10~15%),50HZ |
|||||||||
Output voltage |
AC 10KV~AC 20KV |
|||||||||
Operating Frequency |
10KHz~ 20KHz |
|||||||||
Shipping Efficiency |
> 95% |
|||||||||
Environment Temperature |
-10°C + 40°C |
|||||||||
Environment Humidity |
20%~93% no condensation |
|||||||||
Max treatable width (two-surface)(mm) |
650 |
800 |
1100 |
1300 |
||||||
Aspect side L*D*H(mm) |
480*300*220 |
480*300*320 |
540*340*220 |
540*340*220 |
||||||
Net Weight (kg)(except electrode station) |
10 |
10 |
10 |
18 |
||||||
