Help CenterA4 Size Paper Box Ream Coated Paper Wrapping Machine
Related Products
-
A4 Size 500 Sheets Paper Ream Wrapping MachineUS$ 50,000 - 55,000MOQ: 1 Set -
A4 Size Paper Roll to Sheets Cutting Machine ManufacturerUS$ 50,000 - 55,000MOQ: 1 Set
-
A4 Paper Cutting Machine A3 Copy Paper Roll Sheeting MachineUS$ 30,000 - 32,000MOQ: 1 Set
-
Automatically A4 Sheeting Machine With Best PriceUS$ 30,000 - 32,000MOQ: 1 Set
-
A4 Size 4 Paper Rolls Cutting and Slitting MachineUS$ 20,000 - 50,000MOQ: 1 Set
WHY US?
The Quality We Provide - Outstanding Quality Assurance
Control from production process:
•We don’t send mechanical parts out for pretreatment, all process would be supervised under inspection
department, we have 4sets CNC processing machine.
•7 stages pretreatment meet international standard
•Baking at high temperature after power coating to ensure the paint finish
The Service We Provide - We Take Care Of Your Order
Punctual delivery time:
•We put your order into our tight production schedule, ensure your punctual delivery time.
•Production / inspection report before your order packed.
•Shipping notice/ insurance to you as soon as your order is shipped.
After sales service:
•We respect your feed back after receive the goods.
•We provide 12-24 months warranty after goods arrive.
•We promise all spare parts available in lifetime use.
•We respond your complain within 48hours.
Professional sales:
•We value every inquiry sent to us, ensure quick competitive offer.
•We cooperate with customer to bid tenders. Provide all necessary document.
•We are a sales team, with all technical support from engineer team
Introduction:
The machine is designed by ourselves on basis of producing cellophane overwrapping machine for few years’ experience, which working principle is driven by a series of mechanical structure and connecting pneumatic device, which can finish instantaneously multi-actions such as automatic feeding paper( film), falling paper(film), rectifying a deviation, cutting paper(film),gluing and wrapping and so on during the process of package.
This machine integrated optics, mechanics, electricity, pneumatics and instrumentation . Also reasonable structure, advanced technique, easy operation,which is suitable for the package of global general official A4 format anti-static duplicating paper, instead of hand packing so as to reduce the working intensity and then improve the working effectiveness.
Performance and structure features:
1/Main structure is driven by a series of cams and connecting rods and working accessories to finish the packaging. High stability, low noise.
2/Applying frequency conversion with multi-function digital non-ploy speed, adopting siemens PLC program controlled.
3/Touch screen realizing human-machine interface.
4/ for single paper package, adopting feeding device system so as to input paper accurately.
5/ for roll paper package, It has automatic clutch controlled device to make the roll paper have the function of automatic elevation and subsidence photocell sensor , cutting accuracy of color film.
6/if package material is PE laminated paper,the machine is connecting gluer and the spray adjustable.
if package material is printed film photocell sensor will be provided so as to reduce the packing cost and also improve cutting accuracy of color film, wrapping effect and sealing performance.
BTCP-297 A
Main technical parameters:
Model: |
BTCP-297 A |
Production capacity: |
9-15 (packs/min) |
A4 copy paper size(standard): |
297mmx210mmx50mm |
Voltage: |
380v 50~60hz |
Power: |
5kw |
Compressed air: |
0.6~0.7Mpa |
Overall dimensions: |
4600x1300x1450mm without safety cover 4600x1300x1680mm with safety cover |
Weight: |
1500kg |
Package material |
Printed Single paper |
Electronic parts
NAME |
MODEL |
BRAND |
QTY |
Machine material |
|
Stainless steel |
|
PLC+Touch screen |
|
Siemens |
1
|
Servo motor |
EPS2-TA150L |
DORNA,TAIWAN |
1 |
Frequency convertor |
|
Siemens |
1 |
cylinder |
>=3000Km |
SMC,JAPAN |
23 |
gluer |
|
Shenzheng,China |
1 |
magnetic valve |
4V210-08 |
SMC,JAPAN |
5 |
AC. contractor |
|
siemens |
4 |
relay |
2-15GWZ-B MY2NJ24V |
OMRON |
1 23 |
Main motor/feeding motor |
Y2-802-4 110BYG2502 |
Zhejiang |
1 2 |
circuit breaker |
DZ47-60 1P/1A.3A.5A.10A |
china |
8 |
OIL AND WATER SEPERATOR |
|
SMC,JAPAN |
1 |
electromagnetic relay |
MYLNJ/24VDC |
OMRON |
1 |
switch |
S-50-24 |
taiwan |
1 |
Solid relay |
HHG1-1/032F-22 |
china |
6 |
Industrial chain |
4# |
Shanghai,china |
3 |
