Home > Consumer Electronics > LED Display > Indoor LED Display > Counter Display

Counter Display

Name: Counter Display
Brand: counter display
SKU: 134709845
Availability: InStock

US$ 5.8 - 12 MOQ: 50 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

counter display

Model Number:

DI-C03

Contact Supplier Request Quote Chat Now

Shanghai Diho Electronic Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name counter display

Model Number DI-C03

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Pixels 16mm

Screen Dimension 5x2

Product Description

counter display

Description counter display

1. DIN48*24mm standard panel, 50*60mm extension available

2. Internal Lithium battery, no external power required.

3. 6 or 8 digitals LCD display, big and clear display

4. Panel reset with lock, avoid error operate

5. Input contact or electrical signal, reliable and exact count

6. Top count rate is 200Hz.

7. No mechanical abrasion, long life time, to replace the electromagnetism counter

Specification counter display

Power: internal power

Battery life: appr. 5 year (25℃)

Count range: 0~999999/99999999

Minimum count signal: DI-C03-L 100ms (10Hz)

DI-C03-VL/ DI-C03-AL 50ms (10 Hz)

DI-C03-H 5ms (100 Hz)

DI-C03-VH 2.5ms (200 Hz)

Reset: panel button reset/ external terminal reset

Operating temperature: -10~40℃(no freeze)

Humidity: 35~85%RH

No voltage input:

Max connect resistance: ≤10KΩ (count ON)

Min disconnect resistance: ≥1000KΩ (count OFF)

Voltage input: H valid

(1) L:DC0~2V H:DC4~30V

(2) L:≤5%Ue H:AC220V/110V(85%-110%)

Min reset pulse: ≥0.5s

Weight: appr.60g

Installation dimension: 22.5×45mm

Model counter display

Model	DI-C03- 6L		DI-C03- 6H	DI-C06- 6VL		DI-C03- 6VH	DI-C03- 8L	DI-C03- 8H		DI-C03- 8VL	DI-C03- 8VH
Count rate	10Hz	100Hz		10Hz		200Hz	10Hz	100Hz		10Hz	200Hz
Display	LCD display
Reset	External/panel reset						External/panel reset
Display	6 digital (6.8mm height)						8 digital (6.8mm height)
Reset input	No voltage input (contact or transistor input)				Voltage input		No voltage input (contact or transistor input)		Voltage input
Count input

counter display
