Help CenterKGPS-2Ton Bronze Melting Induction Furnace
Related Products
-
Ferromanganese Smelting Furnace, Ferroalloy Smelting FurnaceUS$ 1,000 - 10,000MOQ: 1 Set -
50kg-10000kg Aluminium Melt and Holding FurnaceUS$ 1,000 - 80,000MOQ: 1 Set
-
Melting Furnace for Aluminum BilletsUS$ 1,000 - 20,000MOQ: 1 Set
-
KGPS-10T Medium Frequency Induction Electric Furnace,metal Melting Electric FurnaceUS$ 1,000 - 80,000MOQ: 1 Set
-
KGPS-5T Aluminium Melt and Holding Furnace ,aluminium Alloy Ingot Melting FurnaceUS$ 1,000 - 80,000MOQ: 1 Set
Induction melting furnace introduction :
Intermediate frequency furnace is a induction heating equipment , Mainly be used in the material of ferrous and non-ferrous metal casting, melting and heating treatment industry , such as iron, steel, brass, cooper ,bronze zinc ,etc. As well as heating treatment prior to forging , sintering and hot rolling in casting and melting industries.
Induction melting furnace Characteristics :
1.Speedy melting, low production cost , low pollution, conforming to environmental protection requirement
2.Flexibly adjustable power, easy and continuous smooth adjustment, easily controllable temperature, low oxidization loss, uniform metal content
3.Furnace shell with cast aluminum ally or steel shell construction, easy overturn body, available for selection of electric, manual, hydraulic or other overturn mode as needed;
Induction melting furnace parameters:
|
Equipment Type (Furnace capacity) |
Power input(Three-phase Four- wire 50/60Hz) | Power Output |
Melting Time (Minutes) |
Power consumption per ton of material (KW) |
|||||||
|
Rating power (KW) |
Input Voltage (V) |
Input Current (A) |
DC Current (A) |
DC Voltage (V) |
IF Voltage (V) |
IF frequency (KHZ) |
Steel (KW) |
Iron (KW) |
Copper (KW) |
||
| KGPS--0.05T | 50 | 380 | 80 | 100 | 500 | 750 | 1-2.5 | 20-60 | 850 | 800 | 450 |
| KGPS--0.1T | 100 | 380 | 160 | 200 | 500 | 750 | 1-2.5 | 20-60 | 800 | 750 | 450 |
| KGPS--0.2T | 160 | 380 | 256 | 320 | 500 | 750 | 1-2.5 | 30-70 | 750 | 700 | 440 |
| KGPS--0.25T | 160 | 380 | 256 | 320 | 500 | 750 | 1-2.5 | 30-70 | 750 | 700 | 440 |
| KGPS--0.3T | 200 | 380 | 320 | 400 | 500 | 750 | 1-2.5 | 30-70 | 700 | 650 | 430 |
| KGPS--0.5T | 250 | 380 | 400 | 500 | 500 | 750 | 1-2.5 | 30-70 | 650 | 600 | 430 |
| KGPS--0.75T | 400 | 380 | 640 | 800 | 500 | 750 | 1-2.5 | 40-70 | 630 | 580 | 400 |
| KGPS--1T | 600 | 380 | 960 | 1200 | 500 | 750 | 0.7-1 | 40-70 | 600 | 560 | 390 |
| KGPS--1.5T | 1000 | 380 | 1600 | 2000 | 500 | 750 | 0.7-1 | 50-70 | 580 | 530 | 380 |
| 660 | 912 | 1140 | 880 | 1300 | |||||||
| KGPS--2T | 1250 | 380 | 2000 | 2500 | 500 | 750 | 0.5-1 | 50-70 | 560 | 520 | 370 |
| 660 | 1140 | 1430 | 880 | 1300 | |||||||
| KGPS--3T | 1500 | 380 | 2400 | 3000 | 500 | 750 | 0.5-1 | 50-80 | 530 | 510 | 350 |
| 660 | 1370 | 1710 | 880 | 1300 | |||||||
| KGPS--5T | 2500 | 380 | 4000 | 3200 | 780 | 1170 | 0.3-1 | 60-90 | 510 | 490 | 340 |
| 660 | 2272 | 2840 | 880 | 1300 | |||||||
| KGPS--10T | 5000 | 660 | 4560 | 5700 | 880 | 1300 | 0.3-1 | 70-100 | 500 | 450 | 320 |
| temperature:1.Steel 1650°C 2.Iron 1450°C 3.Copper 1150 °C 4.Brass 1000 °C 5. Aluminum 700 °C | |||||||||||
Remark:
1.Melting time and power consumption/ton is important to equipment power, raw material shape and weight, operator's skill level and other elements;
2.Configuration :an intermediate frequency power supply,a capacitor cabinet, an overturn control cabinet, body, two sets of reduction boxes and supports, two water cooling cables, etc
3.The above data is of standard model. We also provide customized non-standard products with different power or melting speed.
