Product Details
Place of Origin: | Hebei, China | Brand Name: | XINSHENG | Model Number: | NH-BV |
Insulation Material: | Other, fiber mica | Type: | Low Voltage | Application: | Industrial |
Conductor Material: | Copper | Jacket: | PVC |
Product Description
1.Characteristics of Cable
Application: The cable are widely used for high-temperature, inflammable, control, alarm, fire control situation with voltage 1-10KV.
Characteristics:
Rated voltage: 0.6/1-8.7/10KV; 450/750V; 300/500V; 300/300V.
Rated working temperature: 70℃; 90 ℃; 105 ℃
Short circuit limited temperature: 250 ℃
The environment working temperature should be more than 0 ℃
The turn radius should be more than 15 times of diameter.
Fire resistant function: The cable will continue work more than 90mins under 750-800 ℃ fire.
All other characteristics of this fire-resistant cable are better than the normal type.
Specification:
Type | Name |
NH-VV NH-VLV | PVC fiber mica fluoroplastics insulated fire-resistant power cable |
NH-YJY NH-YJLV | XLPE PVC fiber mica insulated fire retardant power cable |
NH-KVV | PVC fiber mica insulated fire-resistant control power cable |
NH-KVVR | PVC fiber mica insulated fire-resistant control (soft) power cable |
NH-KVVP NH-KVVRP | PVC fiber mica shield insulated fire-resistant control (soft) power cable |
NH-BV | PVC fiber mica insulated fire-resistant wire |
NH-BVR | PVC fiber mica insulated fire-resistant (soft) wire |
NH-BVV | PVC fiber mica insulated fire-resistant cable |
2. Certificate and Test Report
3. Raw material
4. Factory Equipment
5. Our factory
6. Our Project Case
7. Our Engineer
8. Packing and Shipment
9. Our Service
A. For customization Service
All plug, jack and cable can be custom-made according to your request on design, size or materials.
B. Customer Support
We have policies to protect your buy information, no matter you are a private customer or dealer.
C. What can we do?
Provide high quality and the favorite price.
Provide first class service after sale.
Sample free for reasonable quantity.
Delivery on time.
10. Return & Warranty
A. All goods are inspected before shipment.
B. The goods has 1 year warranty for free except custom-made goods.
C. The shipping and handling charge is not refundable and customer should be responsible for all the charges of returning and reshipping.
D. All return Items must be in its original conditions,including box and accessories. People made defects are not guaranteed,such as broken and so on.
FAQ :
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: What is your main products?
A: DC power plug, Headphone plug, DC power cable, Headphone cable &USB cable.
3. Q: What is the material of your products?
A: The material is phosphor bronze & brass & fresh POM & PBT plastic. We can also choose material as customers’ requirement.
4. Q: How does your factory do regarding quality control?
A: Quality is priority. people used to attach great importance to quality controlling from the very beginning to the very end. Our factory has gained RoHS, Reach 84 items, CE, FCC & SGS authentication
5. Q: Are you accept the goods customization?
A: Yes.
6. Q: Does your company provide ODM service for others?
A: Yes.
7. Q: How does your company do if the goods had broken when client received the goods?
A: Client can return the goods but all return goods must be in its original conditions, include carton. Men made defect are not guarantee,such as throw,broken and so on.
