New Design High Power Cob Led Work Light
- Shenzhen
- Credit Card
You May Like
Product Details
| Model Number | X series | Chip Material | InGaN | |
| Emitting Color | Natural White | Luminous Intensity | by distance | |
| Luminous Flux(lm) | 120lm/w | Optical Attenuation(%) | 5 | |
| Power | Other, 3-70, 2-70W | Power Dissipation | 3 | |
| Color Rendering Index(Ra) | 80 | Color Temperature | 2700-6500 | |
| Operating Temperature(℃) | -20, 50 | Storage Temperature(℃) | -20, 50 | |
| Place of Origin | Guangdong, China | Brand Name | Huagao | |
| Certification | CE |
Product Description
Specifications
cob led work light1.Super Bright High Power LED
2.Bridgelux, Epistar chip
3.CE&RoHS certificated
4.3 years warranty
cob led work light
Specification
| Model | IF(mA) | VF(V) | min(LM) | max(LM) | LM/W | CCT(K) | Po(W) | Ra | IPF(mA) |
| HGCT**WW*3-C8X3 | 240 | 34 | 800 | 1000 | 120 | 3000 | 8 | 81 | 900 |
| 360 | 35 | 1200 | 1400 | 120 | 3000 | 12 | 81 | 900 | |
| 450 | 35 | 1500 | 1800 | 110 | 3000 | 16 | 81 | 900 | |
| 720 | 37 | 2000 | 2500 | 90 | 3000 | 27 | 81 | 900 | |
| HGCT**W*6-C7X3 | 240 | 34 | 1000 | 1200 | 130 | 5000 | 8 | 68 | 900 |
| 360 | 35 | 1500 | 1800 | 120 | 5000 | 12 | 68 | 900 | |
| 450 | 36 | 1800 | 2200 | 120 | 5000 | 16 | 68 | 900 | |
| 720 | 38 | 2800 | 3500 | 100 | 5000 | 27 | 68 | 900 | |
| HGCT*W*6-C8X3 | 240 | 34 | 800 | 1000 | 120 | 5000 | 8 | 81 | 900 |
| 360 | 35 | 1200 | 1500 | 120 | 5000 | 12 | 81 | 900 | |
| 450 | 35 | 1500 | 1800 | 110 | 5000 | 16 | 81 | 900 | |
| 720 | 7 | 2200 | 2600 | 90 | 5000 | 27 | 81 | 900 |
Adventages
Products Feature :Using imported Qulity of chip, Phosphor, glue, etc.Spot uniformity, consistency of color, single BIN no color; Single chip Leakage current<5uA; Light efficiency and stability: 1000 hours light decay,3000hours of light decay<3%; Lifespan>50000 hours
Packagingprocess:Independent innovation process, the product is suitable for SMT reflow process. Application: The products main used in indoor lighting, outdoor decorative lighting, commercial lighting, and other types of lighting. such as :LED Downlight ,LED Track Light and Bean pot lamp.
Product presention
cob led work light
Our factory
We are sure your any requirements will get prompt attention!
Contact Us
- Shenzhen Huagao Optoelectronics Technology Co., Ltd.
- Contact nameella Yang Chat Now
- Phone86-755-84501181
- Address3F/Blk C, Xinmusheng Low-Carbon Industry Park, No.6 Xinmu Avenue, Pinghu, Longgang, Shenzhen, China, Shenzhen, Guangdong
