Real MPPT Solar charge controller with constant current driver for solar road lighting control
High efficiency MPPT tracking technology
- Ø MPPT tracking efficiency is 99.9%, the system efficiency is highest at 98%, improve system efficiency and reduce the system cost.
High Conversation Efficiency
- Ø Charging conversion efficiency highest at 98%.
- Ø LED constant current drive efficiency highest at 96%.
- Ø Controller after entering sleep mode, static power consumption current≤2mA.
Flexible parameter setting function
- Ø The infrared wireless communications, and computer connection.
- Ø Friendly man-machine interface, easy to parameter Settings.
- Ø The infrared wireless communication, and handheld remote connection, convenient installation.
The perfect Protection Function
- Ø The battery reverse connect protection.
- Ø Solar panels, reverse connection protection.
- Ø Prevent the battery discharge to the solar panels at night.
- Ø Battery under voltage protection.
- Ø Battery out of under-voltage protection.
|
Model |
Measurement |
||
MCC10/MCC10_Li |
MCC15/MCC15_Li |
|||
|
BATTERY DATA |
Battery voltage |
12/24V auto adapt |
- |
|
Charge current |
10 |
15 |
A |
|
Charging voltage range |
8~30 |
V |
||
MPPT charging voltage @25℃ |
≤14.4(12V), ≤28.8(24V) |
V |
||
Constant charge voltage@25℃ |
14.4(12V), 28.8(24V) |
V |
||
Constant float voltage@25℃ |
13.8(12V), 27.6(24V) |
V |
||
Equalization@25℃(Optional) |
14.8(12V), 29.6(24V) |
V |
||
Discharge stop @25℃ |
11(12V), 22(24V) |
V |
||
Discharge reconnect @25℃ |
12.5(12V), 25(24V) |
V |
||
Temperature compensation |
-4mV/℃/2V |
- |
||
|
PV DATA |
PV Open voltage |
≤60 |
V |
|
PV voltage of close light |
≥6(12V),≥12(24V) |
V |
||
PV voltage of open light |
≤5(12V),≤10(24V) |
V |
||
MPPT tracing range |
14≤Vp≤60(12V),28≤Vp≤60(24V) |
V |
||
|
LED DATA |
Drive LED current |
0~4000 |
mA |
|
Drive LED voltage range |
16~60V(12V), 32V~60V(24V) |
V |
||
Drive LED Max.power |
80(12V),160(24V) |
W |
||
Driving current accuracy |
≤3% |
- |
||
Timer stage |
3 |
- |
||
LED light adjustable range |
0~100 |
% |
||
Paper box;Pallet
OEM Available;
System configuration service;
Technical support.
SUNSUN has its own technical team,including a number of experienced sotrware engineers,hardware engineers,they can customize various specs products and system for clients.
Q:I want to start solar business,but i don't know what product is hot sale!
A:Leave it to us,we will recommed the most fasion hot sale products to you!
Q:I want to use solar system for electical application,but i don't know what components i need!
A:Leave it to use,we will configuration the solar system base on your requirements!
Q:What is the solar charge controller warranty?
A:Solar charge controller 1 year.
