Multi-layer Extrusion Lamination Coating Die

Name: Multi-layer Extrusion Lamination Coating Die
Brand: tiande
Availability: InStock

FOB Price

US$ 2,000 - 5,000 / Set

1 Set(Min. Order)

Port Ningbo/Shanghai Port
Payment TermsT/T Money Gram Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	tiande		Shaping Mode	Extrusion Mould
Product Material	Steel		Product	Other, t-die

Product Description

Product Name	multi-layer extrusion lamination coating die
Usage for products	Plastic film TPU / CPP / CPE / PP / PE / PVC / EVA / / LDPE / HDPE / BOPP / PVB /PC
Product thickness	0.15mm-0.3mm
Die width	300mm-8000mm or per your request
Die material	.2738 from Germany/S316/718/5Crnimo/P20
Lips adjustment system	1.Manual full push flexible fine-turning 2.Automatic full push flexible fine-turning 3.Manual push & pull fine-turning 4.Automatic push & pull fine-turning
Screws	High strength at 12.9 grade
Polishing	Lips and surface of flowing: 0.02-0.03(μm),Other surfaces: 0.03-0.04(μm).
Heat Voltage	220V or on customer’s request
Polishing	Lips and surface of flowing: 0.02-0.03(μm), Other surfaces: 0.03-0.04(μm).
Chrome thickness	0.035-0.045mm
Surface hardness	60-70HR
Installation	On costumer’s request

Products Show

Application fields

About Us

Company information

Taizhou Huangyan Tiande Mold Machinery Co., Ltd. is one of the leading manufacturer in China which specialized in various of plastic extrusion die,include the extrusion flat die head (covering cast film die,oriented film die, sheet die, plate/board die ,film extrusion die heads) ,automatic control die , fast open lip die(fast gap die), coating die, various film dies,various sheet dies, multi-manifold coextrusion dies(Manifold die), single-layer or multi-layer grid hollow plate die (Hollow profile die), hollow special shape product die, foam dies.and ancillary equipments(co-extrusion feedblocks series, melt metering gear pump series, screen changer series, etc. )
With more than 15 years' experience in switch field,Tiande company has mature craft,advanced technology and strong technical power,which enable us to have comprehensive ability on researching,developing, designing and prduction,and present obvious advanced ability and profession.

Customer Photo

Packing & Delivery

Our Service

Tiande Company regards "Quality First, Credit First" as the everlasting topic,it insists on developing business with science & technology and researching and developing new products continuously.Under top quality, excellent service, good reputation.Tiande wishes to cooperate with clients from all over the world to create brilliant future.
