Sitting Type Thermoplastic Road Marking Machine(Scraping)

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Model Number:

DY-STM

Zhengzhou Dayu Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name DY

Model Number DY-STM

Specifications

Sitting Type Thermoplastic Road Marking Machine
1. Engine:Gasoline
2. Paint: Thermoplastic Screeding type
3.Automatic Marking

DY-STM Small Driving Thermoplastic Screeding (Convex) Road Marking Machine

Sitting Type Thermoplastic Road Marking Machine
1. Engine:Gasoline
2. Paint: Thermoplastic Screeding type
3.Automatic Marking

Description of DY-STM Road Marking Machine

DY-STM Small driving thermoplastic screeding (convex) road marking machine is screeding general road marking machine, compact

and small, flexible to operate.Under the premise of sufficient melted material, it also has relatively high construction efficiency.

The type I is for flat line, and the type II is for flat line and convex line.

Main Feature of DY-STM Road Marking Machine

1. Ideal machine for medium-sized and small marking jobs in urban areas and highway.

2. Advanced hydraulic drive with infinitely variable speed control system for precise speed control and adjustment.

3. Moving priority design can be efficiently control machine running to enable the safety in case of emergency.

4. The screeding structure makes the markings straight and beautiful.

5. Sensitive, precise and stable computer control system easily realize all operations.

I: DY-STM-I Small Thermoplastic Road Marking Machine: For flat line

II: DY-STM-II Small Thermoplastic Convex Road Marking Machine: For Flat line and Convex line

Technical Parameter of DY-STM Road Marking Machine

No.	Item	Spec.
1	Engine	Honda Gasoline Engine Electrical Starting
2	Driving System	HTS variable speed transmission system with automatic brake device
3	Heating Mode	Infrared gas heater or injecting diesel heater (alternative)
4	Marking Mode	Screeding with marking shoe
5	Marking Shoe=Line Width	150/200/250/300mm (Optional)
6	Standard Configuration	150mm Marking shoe (High temperature, oxidation and deformation resistance)
7	Paint Tank	160L (hydraulic chain drive horizontal vane blender device, Heating and keeping the temperature automatically)
8	Glass Beads Bin	55L (The automatic quantitative dispenser synchronous with the paint screeding system)
9	Air Compressor	0.6m3/min piston type, with safe automatic exhaust device
10	Electronic Control	Set up various standard line type and Adjust line type
11	Guide Rod	Hydraulic guide rod
12	Warming Function	Warm Lights (Can be adjust flicker frequency)
13	Size and Weight	330014502370mm 910 kg
