Specifications
small asphalt mixing plant manufacturerISO,CE,GOST
12 months warranty
Train your staff
22 years producing experience
20t-100t/h small asphalt mixing plant manufacturer
About us:
As top10 asphalt mixing plant manufacturer of China,Zhengzhou Dayu Machinery Co.,Ltd. established in 1992 and has been focused on small asphalt mixing plant producing for 22 years.
Mainly business scope of Dayu company:
Stationary Asphalt Mixing Plant:
LB series:40t/h--400t/h.(Batch Mix Type) DHB series:20t/h--100t/h.(Drum Mix Type)
Mobile Asphalt Mixing Plant:
MDHB series:20t/h--100t/h.(Drum Mix Type) SLB series:8t/h--30t/h.(Drum Mix Type)
QLB series:10t/h--80t/h.(Batch Mix Type)
Concrete Batching Plant:
Stationary concrete batching plant:HZS series from 25m3/h--150m3/h.
Mobile concrete batching plant:YHZS series from 40m3/h--80m3/h.
Instruction of 20t-100t/h small asphalt mixing plant
DAYU small asphalt mixing plant mainly including:cold aggregate supply system,burner,drying and mixing drum, water dust catcher, bitumen supply system, electric control system.
Drum mixing type asphalt plant, to continuously produce asphalt mixture.
Burning system: oil burner, gas burner and coal burner types.
Technical parameters of small asphalt mixing plant
| Model | Capacity (t/h) | Measurement Accuracy | Total Power (kW) | Fuel Consumption (kg/t) | ||
| Aggregate | Bitumen | Coal | Oil | |||
| DHB/MDHB-20 | 20 | ±1.5% | ±1% | 40 | 10 | 5.5-7 |
| DHB/MDHB-40 | 40 | ±1.5% | ±1% | 75 | 10-13 | 5.5-7 |
| DHB/MDHB-60 | 60 | ±1.5% | ±1% | 128 | 10-13 | 5.5-7 |
| DHB/MDHB-80 | 80 | ±1.5% | ±1% | 165 | 10-13 | 5.5-7 |
| DHB/MDHB-100 | 100 | ±1.5% | ±1% | 200 | 10-13 | 5.5-7 |
Drum dryer
Structure picture
Shipping picture
Installation picture
With strict quality control system
Our Certificates
